节点对RC框架结构抗连续倒塌能力影响研究

李 爽 赵 颖 翟长海 谢礼立

李 爽 赵 颖 翟长海 谢礼立. 节点对RC框架结构抗连续倒塌能力影响研究[J]. 工程力学, 2012, 29(12): 80-87. DOI: 10.6052/j.issn.1000-4750.2011.04.0242
引用本文: 李 爽 赵 颖 翟长海 谢礼立. 节点对RC框架结构抗连续倒塌能力影响研究[J]. 工程力学, 2012, 29(12): 80-87. DOI: 10.6052/j.issn.1000-4750.2011.04.0242
shu
LI Shuang. THE INFLUENCES OF JOINT ON THE PROGRESSIVE COLLAPSE-RESISTING PERFORMANCE OF RC FRAMES[J]. Engineering Mechanics, 2012, 29(12): 80-87. DOI: 10.6052/j.issn.1000-4750.2011.04.0242
Citation: LI Shuang. THE INFLUENCES OF JOINT ON THE PROGRESSIVE COLLAPSE-RESISTING PERFORMANCE OF RC FRAMES[J]. Engineering Mechanics, 2012, 29(12): 80-87. DOI: 10.6052/j.issn.1000-4750.2011.04.0242
shu

节点对RC框架结构抗连续倒塌能力影响研究

  • (1. 哈尔滨工业大学土木工程学院，哈尔滨 150090；2. 中国地震局工程力学研究所，哈尔滨 150080)

基金项目: 国家自然科学基金青年基金项目(51008101)；中国博士后科学基金项目(20100471019)
详细信息

  • 中图分类号: TU318; TU375.4

THE INFLUENCES OF JOINT ON THE PROGRESSIVE COLLAPSE-RESISTING PERFORMANCE OF RC FRAMES

  • (1. School of Civil Engineering, Harbin Institute of Technology, Harbin 150090, China; 2. Institute of Engineering Mechanics, China Earthquake Administration, Harbin 150080, China)

摘要

    摘要
  • 摘要: 为了解节点对结构抗连续倒塌能力的影响，使用按照我国规范设计的RC框架结构对该问题进行了研究。对比了考虑节点影响和不考虑节点影响两种情况下的分析结果，发现节点对结构抗连续倒塌能力影响不能忽略，考虑节点影响后位移反应增大，结构抗连续倒塌的承载力会明显降低。该文同时对锚固在节点区的梁柱钢筋直径和强度、节点区剪切变形、节点区混凝土抗压强度等指标进行了参数分析，分析结果表明锚固在节点区的梁柱钢筋直径和强度对结构抗连续倒塌能力影响显著，而节点区剪切变形和混凝土抗压强度对结构抗倒塌能力基本无影响。此外，研究了考虑节点影响时结构构件的破坏模式，分析结果表明按我国规范设计的RC框架结构在连续倒塌过程中构件仍以弯曲破坏为主，并没有发现构件出现剪切破坏。研究结论为RC框架结构抗连续倒塌设计和加固提供了参考依据。
    Abstract: The influence of structural joints on the progressive collapse-resisting capability of reinforced concrete (RC) frames is studied by employing the structure designed in accordance with Chinese building codes. The comparison of the two numerical models with and without joints indicates that the influences of the joint have a significant effect of increasing the structural displacement responses while decreasing the structural progressive collapse-resisting capability on the progressive collapse-resisting performance of the structure. It is confirmed through the parametric analyses that the diameter and strength of the steel bars have great influences while the joint shear deformation and the concrete compressive strength in joint region have little influence on the progressive collapse-resisting capability of the structure. In addition, the analysis of failure modes of members considering the influence of joints shown that the flexural failure mode remains a dominant failure mode of the members, and no members appear shear failure. The conclusions can be used as references for the progressive collapse-resisting design and strengthening of RC frames.
    • HTML全文
    • 参考文献(15)
  • [1] ASCE 7-05. Minimum design for buildings and other structures [S]. USA: American Society of Civil Engineer, 2006.
    [2] 杜修力, 石磊. 钢结构梁柱抗连续倒塌加固节点[P]. 中国: CN 101736817A, 2010.
    Du Xiuli, Shi Lei. The strengthening beam-column joint of steel structure [P]. China: CN 101736817A, 2010. (in Chinese)
    [3] 胡聪伶. 钢框架连续倒塌动力效应及约束钢梁悬链线效应研究[D]. 长沙: 湖南大学, 2010.
    Hu Congling. Dynamic effects in progressive collapse of steel frame and catenary action of restrained steel beam [D]. Changsha: Hunan University, 2010. (in Chinese)
    [4] Kim T, Kim J. Collapse analysis of steel moment frames with various seismic connections [J]. Journal of Constructional Steel Research, 2009, 65(6): 1316―1322.
    [5] Kim T, Kim J. Progressive collapse-resisting capacity of steel moment frames considering panel zone deformation [J]. Advances in Structural Engineering, 2009, 12(2): 231―240.
    [6] Yu M, Zha X X, Ye J Q. The influence of joints and composite floor slabs on effective tying of steel structures in preventing progressive collapse [J]. Journal of Constructional Steel Research, 2010, 66(3): 442―451.
    [7] Bao Y H, Kunnath S K, EI-Tawil S, et al. Macromodel- based simulation of progressive collapse: RC frame structure [J]. Journal of Structural Engineering, ASCE, 2008, 134(7): 1079―1091.
    [8] 何庆锋. 钢筋混凝土框架结构抗倒塌性能试验应用研究[D]. 长沙: 湖南大学, 2010.
    He Qingfeng. Research on progressive collapse behavior of RC frame structures [D]. Changsha: Hunan University, 2010. (in Chinese)
    [9] Mazzoni S, McKenna F, Scott M H, et al. Open system for earthquake engineering simulation: User Command Language Manual [M]. California: University of California, Berkeley, 2006.
    [10] Yassin M Y M. Nonlinear analysis of prestressed concrete structures under monotonic and cyclic loads [D]. California: University of California, Berkeley, 1994.
    [11] Vecchio F J, Collins M P. The modified compression- field theory for reinforced concrete elements subjected to shear [J]. ACI Journal, 1986, 83(22): 219―231.
    [12] 吴健秋. 基于OpenSEES的梁-柱节点单元的适用性和定参方法研究[D]. 重庆: 重庆大学, 2007.
    Wu Jianqiu. A study on the applicability and parameter defining method of the beam-column model in OpenSEES [D]. Chongqing: Chongqing University, 2007. (in Chinese)
    [13] GB 50010-2002, 混凝土结构设计规范[S]. 北京: 中国建筑工业出版社, 2002.
    GB 50010-2002, Code for design of concrete structures [S]. Beijing: China Architectural & Building Press, 2002. (in Chinese)
    [14] GB 50011-2001, 建筑抗震设计规范[S]. 北京: 中国建筑工业出版社, 2001.
    GB 50010-2001, Code for seismic design of building [S]. Beijing: China Architectural & Building Press, 2001. (in Chinese)
    [15] GSA2003, Progressive collapse analysis and design guidelines for new federal office buildings and major modernization projects [S]. USA: The U.S. General Services Administration, 2003.
