中间主应力对金属悬臂梁承载力的影响

马宗源; 廖红建; 党发宁

doi:10.6052/j.issn.1000-4750.2011.07.0438

中间主应力对金属悬臂梁承载力的影响

(1. 西安理工大学土木建筑工程学院，陕西，西安 710048；2. 西安交通大学土木工程系，陕西，西安 710049)

基金项目: 国家自然科学基金项目(50979087)

详细信息

通讯作者:
马宗源

中图分类号: O344.5
计量
- 文章访问数: 622
- HTML全文浏览量: 20
- PDF下载量: 342
出版历程
- 刊出日期: 2013-01-24

INFLUENCE OF INTERMEDIATE PRINCIPAL STRESS ON BEARING CAPACITY OF METALLIC CANTILEVER BEAMS

(1. School of Civil Engineering and Architecture, Xi’an University of Technology, Xi’an, Shaanxi 710048, China; 2. Department of Civil Engineering, Xi’an Jiaotong University, Xi’an, Shaanxi 710049, China)

摘要

摘要: 基于双剪统一强度理论使用显式有限差分方法对矩形截面金属悬臂梁承载力的中间主应力影响进行了计算分析。通过分析发现，极限状态下悬臂梁的塑性应变的分布非规则圆扇形，而是接近对称三角形分布。中间主应力对悬臂梁承载能力的影响与梁的厚度有关。平面应力情况的悬臂梁比平面应变的中间主应力影响要低，平面应变情况下中间主应力对金属悬臂梁极限承载力的影响与梁的长度无关，平面应力情况下中间主应力影响随梁长度的增加呈先增大后减小而后趋于恒定的趋势。
- 金属悬臂梁 /
- 承载力 /
- 双剪统一强度理论 /
- 中间主应力 /
- 拉格朗日有限差分
Abstract: The influence of the intermediate principal stress on the bearing capacity for a rectangular and metallic cantilever beam was analyzed using the explicit finite difference method and twin shear unified strength theory. The distribution of plastic strain for a cantilever beam under the limit load state is near two symmetry triangles. The influence of the intermediate principal stress on the bearing capacity of a metallic cantilever beam is related to the beam thickness. The influence of the intermediate principal stress on a plane stress beam is lower than that of a plane strain beam. The influence of the intermediate principal stress on the bearing capacity of a plane strain beam is independent of the beam length. The influence of the intermediate principal stress on the bearing capacity of a plane stress beam is increased firstly and decreased secondly with the beam length increased.
- metalic cantilever beam /
- bearing capacity /
- twin shear uni?ed strength theory /
- intermediate principal stress /
- Lagrangian finite difference

HTML全文

参考文献(13)

[1]	Lode W. Versuche ueber den Einlfuss der mittleren Hauptspannung auf dsa fliessen der metals eisen kupfer und nickel [J]. Zeitschrift für Physik A: Hadrons and Nuclei, 1926, 36: 913―939.
[2]	Taylor G I, Quinney H. The plastic distortion of metals [J]. Philosophical Transactions of the Royal Society A: Mathematical, Physical & Engineering Sciences, 1931, 230: 323―362.
[3]	Ivey H J. Plastic stress-strain relations and yield surfaces for aluminum alloys [J]. Journal of Mechanical Engineering Science, 1961, 3: 15―31.
[4]	Mair W M, Pugh H L D. Effect of pre-strain on yield surfaces in copper [J]. Journal of Mechanical Engineering Science, 1964, 6: 150―163.
[5]	周南. 金属屈服准则的试验研究[R]. 天津: 天津大学, 1985. Zhou Nan. Experimental research on the yield criteria of metals [R]. Tianjin: Tianjin University, 1985. (in Chinese)
[6]	Yu M H. Unified strength theory and its applications [M]. Berlin: Springer, 2004: 36―54.
[7]	Yu M H. Advances in strength theories for materials under complex stress state in the 20th century [J]. Applied Mechanics Reviews ASME, 2002, 55(3): 169―218.
[8]	Reddy J N, Wang C M, Lee K H. Exact relationships between the bending solutions of the Euler-Bernoulli beam theory and shear deformable beam theories [J]. International Journal of Solids and Structures, 1997, 34(26): 3373―3384.
[9]	Reddy J N. On locking-free shear deformable beam finite elements [J]. Computer Methods in Applied Mechanics and Engineering, 1997, 149: 113―132.
[10]	ITASCA Consulting Group. FLAC-fast Lagrangian analysis of continua, version 5.0 [R]. Minneapolis: ITASCA Consulting Group, Incorporated, 2005.
[11]	马宗源, 廖红建, 李杭州. 双剪统一弹塑性有限差分方法在金属结构中的应用[J]. 机械工程学报, 2011, 47(2): 36―43. Ma Zongyuan, Liao Hongjian, Li Hangzhou. Application of twin shear unified elastoplastic finite difference method in metallic structures [J]. Chinese Journal of Mechanical Engineering, 2011, 47(2): 36―43. (in Chinese)
[12]	Zienkiewicz. The finite element method in engineering science [M]. New York: McGraw-Hill, 1977: 384―386.
[13]	ANSYS Incorporated. Release 11.0 documentation for ANSYS [R]. USA: ANSYS Incorporated, 2005.
