超低温冻融循环对混凝土材料性能的影响

魏强; 谢剑; 吴洪海

doi:10.6052/j.issn.1000-4750.2012.04.S013

超低温冻融循环对混凝土材料性能的影响

魏强¹,
谢剑^1,2,,
吴洪海¹

1.
天津大学建筑工程学院土木工程系，天津300072；
2.
天津大学滨海土木工程结构与安全教育部重点实验室，天津300072

基金项目: 国家自然科学基金项目(51078260)

详细信息

作者简介:
魏强(1988―)，男，山东人，硕士生，从事低温混凝土结构力学性能试验研究(E-mail:sddzwei@126.com)；吴洪海(1986―)，男，河北人，硕士生，从事低温混凝土结构力学性能试验研究(E-mail:whhai1987@163.com).

通讯作者:
谢剑(1974―)，男，河北人，副教授，博士，硕导，从事混凝土基本理论研究(E-mail:xiejian@tju.edu.cn).

计量
- 文章访问数: 473
- HTML全文浏览量: 22
- PDF下载量: 133
出版历程
- 收稿日期: 2013-06-30
- 修回日期: 2013-06-30
- 刊出日期: 2013-06-24

EXPERIMENTAL ANALYSIS ON PROPERTIES OF CONCRETE AFTER FREEZE-THAW CYCLES UNDER EXTRA-LOW TEMPERATURES

1.
Department of Civil Engineering,Tianjin University,Tianjin 300072,China;
2.
Key Laboratory of Coast Civil Structure Safety,Ministry of Education,Tianjin University,Tianjin 300072,China

摘要

摘要: 借助低温冰箱和超低温加载箱降温的方式，考虑不同混凝土等级、不同冻融次数、不同冻融温度及不同含水量等因素，对63个混凝土立方体试块和21个钢筋混凝土拔出试件进行了冻融循环。通过对冻融循环后立方体试块的强度试验和拔出试件的拔出试验，探究了各因素对混凝土强度及钢筋与混凝土黏结强度的影响。此外，通过对立方体试块残样的SEM电镜扫描试验，揭示了冻融循环对混凝土微观结构的损伤过程及原理。结果表明：水胶比对冻融后混凝土的强度影响较大，添加高效减水剂有助于提高混凝土抵抗冻融破坏的能力；少次数超低温冻融循环对高标号混凝土的强度降低不显著；与混凝土抗压强度相比，低温和超低温冻融循环对抗拉强度的降低作用更加明显；SEM电镜扫描试验有效地解释了混凝土在冻融循环下强度降低的微观机理；少次数超低温冻融循环对钢筋与混凝土黏结强度的降低作用不容忽视。
- 超低温 /
- 冻融循环 /
- 混凝土 /
- 钢筋 /
- 强度 /
- 黏结性能
Abstract: With the cooling system of a low-temperature refrigerator and an extra-low temperature loading box, the freeze-thaw cycle test was carried out for 63 cube specimens and 21 pull-out specimens under different levels, different cycle times, different temperatures and different water contents. Though the test, the influence factors about the strength of concrete and the bonding strength between reinforcement and concrete were studied. Besides, the SEM test was carried out to reveal the damage of microstructures after the freeze-thaw cycles. The results show that: the strength of concrete after freeze-thaw cycles is affected by the water cement ratio obviously, and adding super plasticizer will improve the resistance ability of freeze-thaw damage; with fewer times of freeze-thaw cycles, the influence of strong concrete is not obvious; there is more reduction in tensile strength after freeze-thaw cycles than that in compressive strength; the test of SEM explains the microscopic mechanism after cycles effectively; the bonding strength between reinforcement and concrete has a significantly reduction after 5 freeze-thaw cycles.
- ultra-low temperatures /
- freeze-thaw cycles /
- concrete /
- reinforcement /
- strength /
- bonding properties

HTML全文

参考文献(17)

[1]	陈锦年),(褚健婷),(许兰英). 南极气候和海冰的时空变化特征及其与太平洋海温场的关系[J]. (海洋学报(中文版), 2003(6):39―47. Chen Jinnian, Chu Jianting, Xu Lanying. Spatio-temporal characteristics of antarctic temperature and sea ice and their relationship [J]. Acta Oceanologica Sinica, 20036): 39―47. (in Chinese
[2]	侯文崎),(叶梅新). 青藏铁路钢-混凝土组合结构低温试验研究[J]. (湖南科技大学学报), 2004,19(3):53―57. Hou Wenqi, Ye Meixin. Study of steel-concrete composite structures of Qinghai-Tibet railway under low temperature [J]. Journal of Hunan University of Science & Technology (Natural Science Edition),2004,19(3): 53―57. (in Chinese
[3]	顾安忠). 迎向“十二五”中国LNG的新发展[J]. (天然气工业), 2011,31(6):1―11. Gu Anzhong. Outlook of LNG development in the twelfth Five-Year plan of China [J]. Natural Gas Industry,2011,31(6): 1―11. (in Chinese
[4]	Bamforth. The structural permeability of concrete at cryogenic temperatures [D]. Birmingham: University of Aston, 1987.
[5]	李会杰),(谢剑). 超低温环境下钢筋与混凝土的粘结性能[J]. (工程力学), 2011,28(增刊Ⅰ):80―84. Li Huijie, Xie Jian. Bonding properties between reinforcement and concrete at cryogenic temperatures [J]. Engineering Mechanics,2011,28(SupplⅠ): 80―84. (in Chinese
[6]	Takashi Miura. The properties of concrete at very low temperatures [J]. Materials and Structures, 1989,22:243―254.
[7]	王传星),(谢剑),(李会杰). 低温环境下混凝土性能的试验研究[J]. (工程力学), 2011,28(增刊Ⅱ):182―186. Wang Chuanxing, Xie Jian, Li Huijie. Experimental research on the properties of concrete under low-temperature [J]. Engineering Mechanics,2011,28(SupplⅡ): 182―186. (in Chinese
[8]	王传星),(谢剑),(杨建江). 超低温环境下混凝土的性能[J]. (低温建筑技术), 2009,31(9):8―10. Wang Chuanxing, Xie Jian, Yang Jianjiang. Properties of concrete under extremely low temperature [J]. Low Temperature Architecture Technology,2009,31(9): 8―10. (in Chinese
[9]	山根昭). 超低温混凝土[J]. (低温建筑技术), 1980,2(1):57―60. Shan Genzhao [Japan]. Cryogenic concrete [J]. Low Temperature Architecture Technology,1980,2(1): 57―60. (in Chinese
[10]	Vandewalle L. Bond between a reinforcement bar and concrete at normal and cryogenic temperatures [J]. Journal of Materials Science Letters, 1989,8:147―149.
[11]	Rostasy F S, Schineider U, Wiedemann G. Behavior of mortar and concrete at extremely low temperatures [J]. Cement and Concrete Research, 1979,9(3):365―376.
[12]	Lahlou Dahmani, Amar Khenane, Salah Kaci. Behavior of the reinforced concrete at cryogenic temperatures [J]. Cryogenics, 2007,47:517―525.
[13]	刘爽),(顾祥林),(黄庆华). 超低温下钢筋力学性能的试验研究[J]. (建筑结构学报), 2008,29(增刊I):47―51. Liu Shuang, Gu Xianglin, Huang Qinghua. Experimental study on mechanical properties of steel bars at super-low temperature [J]. Journal of Building Structures, 2008, 29(Suppl I): 47―51. (in Chinese
[14]	刘爽),(黄庆华),(顾祥林). 超低温下钢筋混凝土梁受弯承载力研究[J]. (建筑结构学报), 2009,30(增刊II):86―91. Liu Shuang, Huang Qinghua, Gu Xianglin. Study on bending bearing capacity of reinforced concrete beams at super-low temperature [J]. Journal of Building Structures, 2009, 30(Suppl II): 86―91. (in Chinese
[15]	Liu Shuang, Gu Xianglin, Huang Qinghua. Experimental study on the bending behavior of reinforced concrete beams under super-low temperature [C]// ASCE. Earth and Space 2010: Engineering, Science,Construction, and Operations in Challenging Environments. USA:ASCE, 2010: 3537―3544.
[16]	谢剑),(王传星),(李会杰). 超低温混凝土降温回温曲线的试验研究[J]. (低温建筑技术), 2009,32(3):1―3. Xie Jian, Wang Chuanxing, Li Huijie. Experimental study on the curve of the temperature reduction and comeback in concrete [J]. Low Temperature Architecture Technology,2009,32(3): 1―3. (in Chinese
[17]	吴洪海),(谢剑). 超低温冻融循环作用对混凝土性能的影响[C]//《工程力学》杂志社. 第20届全国结构工程学术会议论文集(第Ⅰ册). 宁波: 《工程力学》杂志社, 2011:403―406. Wu Honghai, Xie Jian. Ultra-low temperature freeze-thaw cycle effects on concrete performance [C]// Engineering Mechanics. 20th National Structure Engineering Conference Proceedings (Volume one). Ningbo:Engineering Mechanics, 2011: 403―406. in Chinese
