航空发动机复合材料机匣叶片包容性研究

刘璐璐, 宣海军, 张娜

刘璐璐, 宣海军, 张娜. 航空发动机复合材料机匣叶片包容性研究[J]. 工程力学, 2013, 30(增刊): 314-319. DOI: 10.6052/j.issn.1000-4750.2012.06.S093
引用本文: 刘璐璐, 宣海军, 张娜. 航空发动机复合材料机匣叶片包容性研究[J]. 工程力学, 2013, 30(增刊): 314-319. DOI: 10.6052/j.issn.1000-4750.2012.06.S093
LIU Lu-lu, XUAN Hai-jun, ZHANG Na. INVESTIGATION ON BLADE CONTAINMENT OF AERO-ENGINE COMPOSITE CASE[J]. Engineering Mechanics, 2013, 30(增刊): 314-319. DOI: 10.6052/j.issn.1000-4750.2012.06.S093
Citation: LIU Lu-lu, XUAN Hai-jun, ZHANG Na. INVESTIGATION ON BLADE CONTAINMENT OF AERO-ENGINE COMPOSITE CASE[J]. Engineering Mechanics, 2013, 30(增刊): 314-319. DOI: 10.6052/j.issn.1000-4750.2012.06.S093

航空发动机复合材料机匣叶片包容性研究

基金项目: 航空推进技术验证计划资助项目(APTD-11);浙江省自然科学基金项目(Y1090245);航空科学基金项目(20095276009);爆炸科学与技术国家重点实验室开放基金项目(KFJJ10-9M)
详细信息
    作者简介:

    刘璐璐(1988―),女,山东曲阜人,博士生,从事航空发动机复合材料机匣包容性数值仿真方法研究(E-mail:liululu@zju.edu.cn);张娜(1988―),女,山东济南人,博士生,从事高速旋转机械测试技术研究(E-mail:zhangna1002@zju.edu.cn).

    通讯作者:

    宣海军(1977―),男,浙江上虞人,副教授,博士,从事高速旋转机械强度、振动和结构冲击响应研究(E-mail:marine@zju.edu.cn).

INVESTIGATION ON BLADE CONTAINMENT OF AERO-ENGINE COMPOSITE CASE

  • 摘要: 为研究复合材料机匣抵抗飞断叶片的包容能力及其损伤破坏机理,在高速旋转试验台上进行缩比模型试验,并采用显式瞬态动力学软件对复合材料机匣的包容机理进行了分析。通过分析叶片与机匣的撞击、击穿过程,研究了复合材料机匣包容机理;通过分析机匣壁厚对机匣破坏方式与包容能力的影响,获取了机匣壁厚与能量吸收的关系。结果表明:飞断叶片与复合材料机匣的撞击过程包含3次撞击,复合材料机匣在内壁与外壁的破坏方式显著不同;随壁厚增加,叶片发生严重的弯曲变形,且机匣能量吸收呈指数倍增加。
    Abstract: To investigate the impact resistance and damage failure mechanisms of a composite aeroengine case, the subscale containment test was conducted on a high speed spin tester and numerical simulations were carried out using an explicit transient dynamic code. The impact process between the released blade and the composite case was investigated to obtain the containment mechanism of the composite case. The influences of the thickness on the failure mode and containment capacity were analyzed to study the correlation of the case thickness and the energy absorption. Containment process usually involves 3 continuous impacts. The failure modes are significantly different in the inner wall and the outer wall of the composite case. The released blade bends more severe and the energy absorption by the composite case increases exponentially with the increase of case thickness.
  • [1] 宣海军),(陆晓),(洪伟荣),等. 航空发动机机匣包容性研究综述[J]. (航空动力学报), 2010,25(8):1860―1870. Xuan Haijun, Lu Xiao, Hong Weirong, et al. Review of aero-engine case containment research [J]. Journal of Aerospace Power,2010,25(8): 1860―1870. (in Chinese
    [2] Littell J D, Binienda W K, Roberts G D,et al. Characterization of damage in triaxial braided composites under tensile loading [J]. Journal of Aerospace Engineering, 2009,22(3):270―279.
    [3] Ruggeri C. High strain rate data acquisition of 2D braided composite structures [D]. USA: The University of Arkon, 2009.
    [4] Staniszewski M. Simulation of tri-axially braided composites half-cylinder behavior during ballistic impact [D]. USA: The University of Akron, 2007.
    [5] Goldberg R K, Blinzler B J, Binienda W K. Modification of a macromechanical finite-element based model for impact analysis of triaxially braided composites [J]. Journal of Aerospace Engineering, 2012,25(3):383―394.
    [6] Roberts G D, Pereira J M, Jr. Revilock D M, et al. Ballistic impact of braided composite with a soft projectile [J]. Journal of Aerospace Engineering, 2005,18(1):3―7.
    [7] Sutcliffe M P F, Aceves C M, Stronge W J,et al. Moderate speed impact damage to 2D-braided glass-carbon composites [J]. Composite Structures, 2012,94(5):1781―1792.
    [8] FAA/SAE committee on uncontained turbine engine rotor events [R]. Washington, D. C., USA: Federal Aviation Administration,1994.
    [9] Stotler C L, Coppa A P. Containment of composite fan blades [R]. Cleveland Ohio, USA: NASA - Lewis Research Center,1979.
    [10] Stotler C L. Development of advanced lightweight system containment-Final report [R]. Cleveland Ohio, USA: NASA - Lewis Research Center,1981.
    [11] Naik D, Sankaran S, Mobasher B,et al. Development of reliable modeling methodologies for fan blade out containment analysis. Part I: Experimental studies [J]. International Journal of Impact Engineering, 2009,36(1):1―11.
    [12] Stahlecker Z, Mobasher B, Rajan S D,et al. Development of reliable modeling methodologies for engine fan blade out containment analysis. Part II: Finite element analysis [J]. International Journal Impact Engineering, 2009,36(3):447―459.
    [13] Shockey D A, Erlich D C, Simons J W. Improved barriers turbine engine fragments: interim report I [R]. Washington DC, USA: Federal Aviation Administration,2002.
    [14] Roberts G D, Revilock D M, Binienda W K. Impact testing and analysis of composites for aircraft engine fan cases [J]. Journal of Aerospace Engineering, 2002,15(3):104―110.
    [15] 刘璐璐),(宣海军),(何庆),等. 复合材料机匣受叶片撞击损伤过程研究[J]. (兵工学报), 2011,32(增刊2):264―268. (in Chinese) Liu Lulu, Xuan Haijun, He Qing, et al. Damage process of composite aero-engine case impact by blade [J]. Acta Armamentari, 2011, 32(Suppl 2): 264―268. (in Chinese
    [16] Matzenmillar A, Lubliner J, Taylor R L. A constitutive model for anisotropic damage in fiber composites [J]. Mechnical Material, 1995,20:125―52.
    [17] Hashin Z. Failure criteria for unidirectional fiber composites [J]. Journal of Applied Mechanics, 1980,47(6):329―334.
    [18] He Qing, Xuan Haijun, Liu Lulu. Perforation of aero-engine fan casing by a single rotating blade [J]. Aerospace Science and Technology, 2013,25(1):234―241.
