UNIFIED HEAT TRANSFER MODEL OF VERTICAL U-TUBE HEAT EXCHANGERS FOR GROUND SOURCE HEAT PUMP SYSTEM
-
摘要: 该文建立了垂直地埋管换热器传热理论模型,该模型能考虑钻孔内比热容和地埋管内循环液体沿竖直方向的对流换热。基于该理论模型编制了相应的计算软件,分析了竖直地埋管换热器钻孔内材料参数对其换热效率的影响。计算结果表明：当钻孔内回填料的导热系数较大、U形管两臂较近时,两臂之间会发生明显的热短路现象；U形管两臂间距越大,换热效率越高；U形管管径越大,换热效率越高；回填料的比热容对地埋管的换热效率在短期内有一定影响,当地埋管地源热泵系统长期运行时,回填料比热容的影响可以忽略；钻孔内回填料的导热系数对地埋管的换热效率有较大影响,当其小于岩土层导热系数时,地埋管的换热效率会随回填料导热系数的增大而较快提高；但当其大于岩土层导热系数时,由于两臂间的热短路增强,地埋管的换热效率随回填料导热系数的增加而趋于平缓。Abstract: A theoretical model of U-tube heat exchangers for a ground source heat pump (GSHP) system was established by taking into account the specific heat of backfill grouting and the vertical heat convection of flow inside a U tube. The influence of the parametric, such as the thermal properties of backfill grouting, the arm distance and the diameter of a U-tube, upon the efficiency of the thermal conversion of a U-tube was analyzed. The calculated results show that the heat cutting-out between the two arms of the U-tube would occur when they are closed. The bigger of the distance of the arms and the diameter of the U-tube, the higher efficiency of the thermal conversion would be obtained. The specific heat of the backfill grouting can influence the efficiency of the thermal conversion of the U-tube in a shorter operation time period, which could be ignore in a longer operation time period. The thermal conductivity of backfill grouting could influence the efficiency of the U-tube significantly. When the thermal conductivity of backfill grouting is bigger than that of soil, the efficiency of a U-tube would increase rapidly. When it is less than the thermal conductivity of soil, the change will become slow due to the cutting-out of heat.
-
-
[1] Eskilson P. Thermal analysis of heat extraction boreholes [D]. Sweden: University of Lund, 1987. [2] Hellström G. Ground heat storage: Thermal analyses of duct storage systems [D]. Sweden: Lunds University, 1991. [3] Yavuzturk C. Modeling of vertical ground loop heat exchangers for ground source heat pump systems [D]. Oklahoma State University, 1988. [4] Kavanaugh S. Simulation and experimental verification of vertical ground-coupled heat pump systems [D]. Oklahoma State University, 1985. [5] 刘宪英, 胡鸣明, 魏唐棣, 等. 地热源热泵地下埋管换热器传热模型的综述[J]. 重庆垃筑大学学报, 1999, 21(4): 106―111. Liu Xianying, Hu Mingming, Wei Tangdi, et al. Development of modeling of the underground heat exchanger for GSHP [J]. Journal of Chongqing Jianzhu University, 1999, 21(4): 106―111. (in Chinese) [6] Ingersoll I L R, Plass H J. Theory of the ground pipe heat source for the heat pump [J]. ASHVE Transactions, 1948, 6(1): 119―122. [7] 柳晓雷, 王德林, 方肇洪. 垂直埋管地热换热器的传热模型与计算[J]. 建筑热能通风空调, 2001(2): 1―3.
Liu Xiaolei, Wang Deling, Fang Zhaohong. Modeling on heat transfer of a vertical bore in geothermal heat exchangers [J]. Building Energy & Environment, 2001(2): 1―3. (in Chinese)[8] 刁乃仁, 方肇洪. 地埋管地源热泵技术[M]. 北京: 高等教育出版社, 2006: 20―31. Diao Nairen, Fang Zhaohong. Ground-coupled pump technology [M]. Beijing: Higher Education Press, 2006: 20―31. (in Chinese) [9] Bennet J, Claesson J, Hellström G. Multipole method to compute the conductive heat flows to and between pipes in a composite cylinder [D]. Notes on Heat Transfer 3-1987, Dept. of Building Technology and Mathematical Physics, Lund Institute of Technology, Sweden, 1987. [10] Cui P, Yang H, Fang Z. Numerical analysis and experimental validation of heat transfer in ground heat exchangers in alternative operation modes [J]. Energy and Building, 2008, 40(6): 1060―1066. [11] 陈忠购, 赵石娆, 张正威. 内置并联U形埋管能量桩的换热性能研究[J]. 工程力学, 2013, 30(5): 238―243.
Chen Zhonggou, Zhao Shirao, Zhang Zhengwei. Heat transfer analysis of energy piles with parallel connected U-tubes [J]. Engineering Mechanics, 2013, 30(5): 238―243. (in Chinese) 注：该文在第21届结构工程学术会议(2012 沈阳)应邀作特邀报告 -
