FRP约束RC矩形空心截面桥墩分析模型及试验验证

董振华, 韩强, 杜修力

董振华, 韩强, 杜修力. FRP约束RC矩形空心截面桥墩分析模型及试验验证[J]. 工程力学, 2013, 30(12): 57-64. DOI: 10.6052/j.issn.1000-4750.2012.08.0623
引用本文: 董振华, 韩强, 杜修力. FRP约束RC矩形空心截面桥墩分析模型及试验验证[J]. 工程力学, 2013, 30(12): 57-64. DOI: 10.6052/j.issn.1000-4750.2012.08.0623
DONG Zhen-hua, HAN Qiang, DU Xiu-li. ANALYTICAL MODEL AND EXPERIMENTAL VALIDATION OF FRP CONFINED BRIDGE COLUMNS with RC RECTANGULAR HOLLOW CROSS SECTIONS[J]. Engineering Mechanics, 2013, 30(12): 57-64. DOI: 10.6052/j.issn.1000-4750.2012.08.0623
Citation: DONG Zhen-hua, HAN Qiang, DU Xiu-li. ANALYTICAL MODEL AND EXPERIMENTAL VALIDATION OF FRP CONFINED BRIDGE COLUMNS with RC RECTANGULAR HOLLOW CROSS SECTIONS[J]. Engineering Mechanics, 2013, 30(12): 57-64. DOI: 10.6052/j.issn.1000-4750.2012.08.0623

FRP约束RC矩形空心截面桥墩分析模型及试验验证

基金项目: 国家自然科学基金项目(50908005,50938006)
详细信息
    作者简介:

    董振华(1984―),女,内蒙古人,博士生,主要从事结构抗震加固方面的研究(E-maildongzhenhua2009@126.com);杜修力(1962―),男,四川人,教授,博士,博导,主要从事地震工程与结构动力学等方面的研究(E-mailduxiuli@bjut.edu.cn).

    通讯作者:

    韩强(1974―),男,河南人,副教授,博士,主要从事桥梁抗震方面的研究(E-mail:qhan@live.com);

  • 中图分类号: U443.2

ANALYTICAL MODEL AND EXPERIMENTAL VALIDATION OF FRP CONFINED BRIDGE COLUMNS with RC RECTANGULAR HOLLOW CROSS SECTIONS

  • 摘要: 针对纤维复合材料(FiberReinforcedPolymer,FRP)约束钢筋混凝土(RC)矩形空心截面墩的抗震性能分析问题,该文提出了一种考虑有效强度系数和面积配箍率的FRP有效侧向约束力的简化计算方法。并通过与试验体桥墩的墩顶水平位移-承载力、墩底截面转动变形-弯矩曲线的对比分析,验证了该文提出简化计算模型的正确性。最后,基于该文提出的简化计算方法,对不同种类FRP约束RC矩形空心截面墩截面的抗弯承载力、曲率、塑性转动能力等抗震性能参数进行了研究,结果表明环包FRP布对空心墩的延性贡献较大,对提高其承载力影响较小。
    Abstract: In order to evaluate aseismic performance of Fiber Reinforced Polymer (FRP) confined reinforced concrete (RC) rectangular hollow-bridge columns, a simplified confined concrete model of FRP is proposed by considering the effective strength coefficient and area distribution ratio of FRP hoops. The proposed simplified analytical model is validated to be right and effective by comparing the test results and calculation results of lateral forces vs deformations at the top of bridge piers and rotation deformations vs moments at the bottom section of bridge column specimens. Based on the improved analytical model presented, aseismic performance parameters of flexural capacity, curvature, the plastic rotation capacity of cross sections of a RC rectangular hollow section pier restrained by different types of FRP are investigated. The results show that the loop packaged FRP cloth has a more considerable effect on ductility than the load capacity of FRP restricted RC rectangular hollow-bridge columns.
  • [1] JTJ 004-89, 公路工程抗震设计规范[S]. 北京: 人民交通出版社, 1990.
    [2] JTJ 004-89, Code for seismic design of highway engineering [S]. Beijing: People Transportation Press, 1990. (in Chinese)
    [3] [2]贡金鑫, 王雪婷, 张勤. 从汶川地震灾害看现行国内外桥梁抗震设计方法[J]. 大连理工大学学报, 2009, 5(49): 739―747.
    [4] Gong Jinxin, Wang Xueting, Zhang Qin. Overview on current bridge seismic design approach in home and abroad codes basedon survey of Wenchuan earthquake [J]. Journal of Dalian University of Technology, 2009, 5(49): 739―747. (in Chinese)
    [5] [3]Han Qiang, Du Xiuli, Liu Jingbo. The seismic damage of highway bridges during 2008 Wenchuan earthquake [J]. Earthquake Engineering and Engineering Vibration, 2009, 8(2): 263―273.
    [6] [4]JTG/T B02-01-2008, 公路桥梁抗震设计细则[S]. 北京:人民交通出版社, 2008.
    [7] JTG/T B02-01-2008, Guidelines for seismic design of highway bridges [S]. Beijing: People Transportation Press, 2008. (in Chinese)
    [8] [5]JTG/T J022-2008, 公路桥梁加固设计规范[S]. 北京: 人民交通出版社, 2008.
    [9] JTG/T J022-2008, Specifications for strengthening design of highway bridges [S]. Beijing: People Transportation Press, 2008. (in Chinese)
    [10] [6]Kumutha R, Vaidyanathan R, Palanichamy M S. Behaviour of reinforced concrete rectangular columns strengthened using GFRP [J]. Cement Concrete Composites, 2007(29): 609―615.
    [11] [7]Yeh Y K, Mo Y L, Yang C Y. Seismic performance of rectangular hollow bridge columns [J]. Journal of Structural Engineering, 2002, 128(1): 60―68.
    [12] [8]Lam L, Teng J G. Design-oriented stress-strain model for FRP-confined concrete [J]. Construction and Building, Materials, 2003, 17: 471―489.
    [13] [9]Toutanji H, Saafi M. Stress-strain behavior of concrete columns confined with hybrid composite materials [J]. Materials and Structures, 2002, 7(35): 338―347.
    [14] [10]Teng J G, Huang Y L, Lam L, et al. Theoretical model for fiber-reinforced-polymer-confined concrete [J]. Journal of Composites for Construction, 2007, 11(2): 201―210.
    [15] [11]Theodoros C Rousakisa, Athanasios I Karabinisa, Panos D Kiousisb. FRP-con#x0fb01;ned concrete members: axial compression experiments and plasticity modeling [J]. Engineering Structures, 2007, 29: 1343―1353.
    [16] [12]Jason Fitzwilliam, Luke A Bisby. Slenderness effects on circular CFRP con#x0fb01;ned reinforced concrete columns [J]. Journal of Composites for Construction, 2010, 14(3): 280―288.
    [17] [13]Hasan A Moghaddam, Maysam Samadi. On the effect of ductility of confining material on concrete ductility [J]. Structural Engineers, 2009, 4(341): 259―269.
    [18] [14]Lignola G P, Prota A, Manfredi G, et al. Experimental performance of RC hollow columns con#x0fb01;ned with CFRP [J]. Journal of Composites for Construction, 2007, 1(11): 42―50.
    [19] [15]Yuliarti Kusumawardaningsih, Hadi M N S. Comparative behaviour of hollow columns confined with FRP composites [J]. Composite Structures, 2010, 1(99): 1―23.
    [20] [16]Mander J B, Priestley M J N, Park R. Theoretical stress- strain model for confined concrete [J]. Journal of Structural Engineering, 1988, 8(114): 1804―1826.
