基于网格/无网格的三维超音速流场数值模拟

蔡晓伟; 谭俊杰; 王园丁; 任登凤

doi:10.6052/j.issn.1000-4750.2013.06.0558

基于网格/无网格的三维超音速流场数值模拟

南京理工大学能源与动力工程学院，南京 210094

基金项目: 国家自然科学基金项目(11072114)

详细信息

作者简介:
蔡晓伟(1987-), 男, 江苏人, 博士生, 主要从事无网格方法研究(E-mail:davidcaixw@gmail.com); 王园丁(1987-), 男, 江苏人, 博士生, 主要从事大涡模拟研究(E-mail:xiaocai2601@163.com); 任登凤(1979-), 女, 江苏人, 讲师, 硕士, 主要从事计算传热学、工程热物理研究(E-mail:rendengfeng@mail.njust.edu.cn).

通讯作者:
谭俊杰(1949-), 男, 湖南人, 教授, 硕士, 博导, 主要从事流体力学计算和实验研究(E-mail:dlxyjx@mail.njust.edu.cn).

中图分类号: O354
计量
- 文章访问数: 273
- HTML全文浏览量: 22
- PDF下载量: 80
出版历程
- 收稿日期: 2013-06-18
- 修回日期: 2013-12-08
- 刊出日期: 2014-12-24

NUMERICAL SIMULATION FOR THREE-DIMENSIONAL SUPERSONIC FLOW FIELD BASED ON HYBRID GRID/MESHLESS ALGORITHM

School of Energy and Power Engineering, Nanjing University of Science and Technology, Nanjing 210094, China

摘要

摘要: 该文针对绕三维复杂外形流动的数值模拟，提出了一套基于笛卡尔网格/无网格的混合算法。该算法采用计算效率高的笛卡尔网格覆盖全场，而在计算物体表面及周围邻近区域布置无网格离散点。通过对重叠区域的划分和信息传递，建立各计算区域之间的耦合关系，形成完整的计算系统。为验证混合算法数值模拟的适用性和准确性，该文对超音速圆球绕流进行了计算，将激波的位置、形状与理论分析结果进行了对比。并进一步采用该算法对Ma=2.5、0°~10°攻角下的B1AC2R标准导弹模型进行了计算，获得的气动力系数与实验值基本吻合，表明该文提出的方法可以进行实际工程应用。
- 复杂外形 /
- 超音速 /
- 笛卡尔网格 /
- 无网格法 /
- 耦合关系
Abstract: To simulate three-dimensional flow around complex geometrics, a hybrid method based on Cartesian grid and meshless method is presented. In this hybrid method, the efficient Cartesian grid covers the whole computational domain, while a relatively small domain adjacent to the body surface is covered by meshless points. By implementing domain identification and information communication in the overlapping domain, several computational domains are coupled together, and the complicated computational system is formed. To validate the applicability and accuracy of this hybrid method, the supersonic sphere flow is calculated, and the location and the shape of the shock obtained are compared with the empirical formula data. The B1AC2R generic missile at Ma=2.5 and angles of attack 0°~10° is also simulated, the computational results including the aerodynamic coefficients are in a good agreement with the experimental data. It is found that the hybrid method presented is available for actual engineering problems.
- complex geometrics /
- supersonic /
- cartesian grid /
- meshless method /
- coupled relationship

HTML全文

参考文献(17)

[1]	张雄, 宋康祖, 陆明万. 无网格法研究进展及其应用[J]. 计算力学学报, 2003, 20(6): 730―742. Zhang Xiong, Song Kangzu, Lu Mingwan. Research progress and application of meshless method [J]. Chinese Journal of Computational Mechanics, 2003, 20(6): 730―742. (in Chinese)
[2]	史宝军, 袁明武, 宋世军. 流体力学问题基于核重构思想的最小二乘配点法[J]. 工程力学, 2006, 23(4): 17―21. Shi Baojun, Yuan Mingwu, Song Shijun. Least-square point collocated meshless method based on kernel reproducing for hydrodynamic problems [J]. Engineering Mechanics, 2006, 23(4): 17―21. (in Chinese)
[3]	Batina J. A gridless Euler/Navier-Stokes solution algorithm for complex two-dimensional application [R]. Hampton, VA, USA. NASA (National Aeronautics and Space Administration), 1993: 333―341.
[4]	Sridar S, Balakrishnan N. An upwind finite difference scheme for meshless method [J]. Journal of Computational Physics, 2003, 189(1): 1―29.
[5]	Katz A. Meshless methods for computational fluid dynamics [D]. Ann Arbor, Michigan: ProQuest, UMI Dissertation Publishing, 2009.
[6]	蔡晓伟, 谭俊杰, 王园丁, 等. 两种k-ω型湍流模型在无网格方法中的应用研究[J]. 空气动力学学报, 2014, 32(5): 273―279. Cai Xiaowei, Tan Junjie, Wang Yuanding, et al. Application and analysis of two k-ω type turbulence models in meshless method [J]. Acta Aerodynamic Sinica, 2014, 32(5): 273―279. (in Chinese)
[7]	Ortega E, Onate E, Idelsohn S. A finite point method for adaptive three-dimensional compressible flow calculations [J]. International Journal for Numerical Methods in Fluids, 2009, 60(9): 937―971.
[8]	Kirshman D J, Liu F. A gridless boundary condition method for the solution of the Euler equations on embedded Cartesian meshes with multigrid [J]. Journal of Computational Physics, 2004, 201(1): 119―147.
[9]	Cai X W, Tan J J, Ma X J, et al. Application of hybrid Cartesian grid and gridless approach to moving boundary flow problems [J]. International Journal for Numerical Methods in Fluids, 2013, 72(9): 994―1013.
[10]	Liou M S, Christopher J, Steffen J. A new flux splitting scheme [J]. Journal of Computational Physics, 1993, 107(1): 23―39.
[11]	Liou M S. A sequel to AUSM, PartⅡ: AUSM+-up for all speeds [J]. Journal of Computational Physics, 2006, 214(1): 137―170.
[12]	Lerat A, Wu Z N. Stable conservative multidomain treatments for implicit Euler solvers [J]. Journal of Computational Physics, 1996, 123(1): 45―64.
[13]	Chesshire G, Henshaw W D. Composite overlapping meshes for the solution of partial differential equations [J]. Journal of Computational Physics, 1990, 90(1): 1―64.
[14]	Berger M J. On conservation at grid interfaces [J]. SIAM Journal on Numerical Analysis, 1986, 24(5): 96―984.
[15]	Billig F S. Shock-wave shapes around spherical- and cylindrical-nosed bodies [J]. Journal of Spacecraft and Rockets, 1967, 4(6): 822―823.
[16]	Despirito J. Base pressure computations of the DERA generic missile wind tunnel model [R]. Maryland, USA, Army Research Laboratory, 2005: 1―21.
[17]	Despirito J, Edge H L, Weinacht P, et al. Computational fluid dynamic (CFD) analysis of a generic missile with grid fins [J]. Journal of Spacecraft and Rockets, 2001, 38(5): 711―718.
