型钢再生混凝土框架-空心砌块墙抗侧刚度试验研究

薛建阳; 雷思维; 高亮; 罗峥; 刘菲

doi:10.6052/j.issn.1000-4750.2013.08.0765

型钢再生混凝土框架-空心砌块墙抗侧刚度试验研究

西安建筑科技大学土木工程学院,陕西,西安 710055

基金项目: 国家自然科学基金项目(51178384); 陕西省留学人员科技活动择优项目(陕外专发[2010]26号); 住房和城乡建设部科学技术项目(2012-K2-12); 教育部创新团队发展计划项目(RT13089); 西安建筑科技大学创新团队发展计划项目

详细信息

作者简介:
雷思维(1987―),湖北十堰人,硕士生,主要从事钢与混凝土组合结构研究(E-mail: 674493595@qq.com);高亮(1985―),山东济南人,博士生,主要从事钢与混凝土组合结构研究(E-mail: 627341793@qq.com);罗峥(1988―),陕西西安人,硕士生,主要从事钢与混凝土组合结构研究(E-mail: 80559849@qq.com);刘菲(1987―),陕西渭南人,硕士生,主要从事钢与混凝土组合结构研究(E-mail: 348804233@qq.com).

通讯作者:
薛建阳(1970―),河南洛阳人,教授,博士,主要从事钢与混凝土组合结构及工程结构的抗震研究(E-mail: jianyang_xue@163.com).

中图分类号: TU398
计量
- 文章访问数: 269
- HTML全文浏览量: 19
- PDF下载量: 76
出版历程
- 收稿日期: 2013-08-20
- 刊出日期: 2015-03-24

EXPERIMENTAL STUDY ON LATERAL STIFFNESS OF STEEL RECYCLED CONCRETE FRAME WITH RECYCLED CONCRETE HOLLOW BLOCK WALL

College of Civil Engineering, Xi’an University of Architecture and Technology, Xi’an, Shaanxi 710055, China

摘要

摘要: 为研究型钢再生混凝土结构(SRRC)的抗侧力性能,进行了3榀不同填充程度的型钢再生混凝土框架-再生混凝土空心砌块墙体混合结构的低周反复荷载试验。通过测试试件在侧向力作用下的受力过程和破坏形态,研究型钢再生混凝土框架结构的受力机理和抗震性能,获得了再生混凝土空心砌块墙体对框架的承载力和抗侧刚度的影响;分析结构在不同受力阶段的承载力和刚度变化情况,以及结构在同级循环荷载作用下的刚度退化规律。结果表明：型钢再生混凝土框架-再生混凝土空心砌块填充墙结构具有较高的承载力和抗侧刚度,全高填充墙对型钢再生混凝土框架抗侧刚度的影响较大,结构初始刚度大,而刚度衰减快,半高填充墙在结构受力初期可提高结构承载力和刚度,而在受力后期具有与空框架相似的退化规律。
- 型钢再生混凝土 /
- 低周反复荷载 /
- 填充墙 /
- 水平承载力 /
- 抗侧刚度
Abstract: In order to study the lateral resistance of shaped steel-recycled concrete structures, low-cyclic reversed loading tests were carried out on 3 models of a shaped steel recycled concrete- recycled concrete hollow block wall hybrid structure. Based on the loading process and failure pattern of the specimens, the mechanical performance and seismic behavior of the shaped steel recycled concrete columns-reinforced recycled concrete beam structure were studied, and the influence of the recycled concrete hollow block wall on the bearing capacity and lateral stiffness of the frame was obtained. The changes in bearing capacity and stiffness of the structure under different loading phases and the rules governing structural stiffness degradation under circulating load at one level was analyzed. It was found that shaped steel recycled concrete frames with recycled concrete hollow block wall structure has high bearing capacity and lateral stiffness. A full-height wall has a great influence on the lateral stiffness. It has high initial stiffness, however that stiffness decreases rapidly. With a half-height wall, the structure has increased bearing capacity and stiffness at the initial loading stage, but displays degradation of bearing capacity and lateral stiffness similar to the bare frame’s.
- shaped steel recycled aggregate concrete /
- low-cyclic reversed loading /
- infilled wall /
- horizontal bearing capacity /
- lateral stiffness

HTML全文

参考文献(13)

[1]	肖建庄. 再生混凝土[M]. 北京: 中国建筑工业出版社, 2002: 56―63. Xiao Jianzhuang. Recycled concrete [M]. Beijing: China Architecture and Building Press, 2002: 56―63. (in Chinese)
[2]	孙跃东, 肖建庄, 周德源, 等. 再生轻质砌块填充墙再生混凝土框架抗震性能的试验研究[J]. 地震工程与工程震动, 2005, 10(5): 124―131. Sun Yuedong, Xiao Jianzhuang, Zhou Deyuan, et al. Experimental research on seismic behavior of recycled concrete frame filled with recycled light weight masonry blocks [J]. Earthquake Engineering and Engineering Vibration, 2005, 10(5): 124―131. (in Chinese)
[3]	Fathifazl G, Razaqpur A G, Isgor O B, et al. Flexural performance of steel-reinforced recycled concrete beams [J]. Materials Journal, 2009, 106(6): 858―867.
[4]	薛建阳, 马辉, 陈宗平, 等. 型钢再生混凝土柱保护层厚度力学分析[J]. 工程力学, 2013, 30(5): 202―206. Xue Jianyang, Ma Hui, Chen Zongping, et al. Mechanical analysis on the cover thickness of steel reinforced recycled concrete column [J]. Engineering Mechanics, 2013, 30(5): 202―206.(in Chinese)
[5]	蒋利学. 砖填充墙加固前后钢筋混凝土框架的刚度与承载力[J]. 工业建筑, 2009, 39(增刊): 181―185. Jiang Lixue. Stiffness and load carrying capacity of reinforced concrete with infilled wall or strengthened infilled wall [J]. Industrial Construction, 2009, 39(Suppl): 181―185. (in Chinese)
[6]	刘玉姝, 李国强. 带填充墙钢框架结构抗侧力性能试验及理论研究[J]. 建筑结构学报, 2005, 26(3): 78―84. Liu Yushu, Li Guoqiang. Experimental and theoretic research on lateral load resistance of steel frames with infilled walls [J]. Journal of Building Structures, 2005, 26(3): 78―84. (in Chinese)
[7]	童岳生, 钱国芳. 砖填充墙钢筋混凝土框架的变形性能及承载能力[J]. 西安冶金建筑学院学报(自然科学版), 1985, 42(2): 1―10. Tong Yuesheng, Qian Guofang. Deformation behavior and load capacity of reinforced concrete frames with brick filler walls [J]. Journal of Xi’an University of Architecture & Technology (Natural Science Edition), 1985, 42(2): 1―10. (in Chinese)
[8]	Asteris P G. Lateral stiffness of brick masonry infilled plane frames [J]. Journal of Structural Engineering, 2003, 129(8): 1071―1079.
[9]	Mondal G, Jain S K. Lateral stiffness of masonry infilled reinforced concrete (RC) frames with central opening [J]. Earthquake Spectra: August, 2008, 24(3): 701―723.
[10]	薛建阳, 刘祖强, 葛鸿鹏, 等. 实腹式型钢混凝土异形柱中框架抗震性能试验研究[J]. 建筑结构学报, 2011, 32(11): 82―88. Xue Jiangyang, Liu Zuqiang, Ge Hongpeng, et al. Seismic behavior of solid steel reinforced concrete middle frame with special- shaped columns [J]. Journal of Building Structures, 2011, 32(11): 82―88. (in Chinese )
[11]	曹万林, 王光远, 吴建有, 等. 轻质填充墙异形柱框架结构层刚度及其衰减过程的研究[J]. 建筑结构学报, 1995, 16(5): 20―31. Cao Wanlin, Wang Guangyuan, Wu Jianyou, et al. Study on the story stiffness and its degeneration of frame with light weight infilling and special shape columns [J]. Journal of Building Structures, 1995, 16(5): 20―31. (in Chinese)
[12]	姚谦峰, 陈平. 土木工程结构试验[M]. 北京: 中国建筑工业出版社, 2001: 219―220. Yao Qianfeng, Chen Ping, Civil engineering structural experiment [M]. Beijing: China Architecture & Building Press, 2001: 219―220. (in Chinese)
[13]	薛建阳, 高亮, 刘祖强, 等. 空腹式型钢混凝土异形柱中框架抗侧刚度试验研究[J]. 工程力学, 2013, 30(9): 34―46. Xue Jianyang, Gao Liang, Liu Zuqiang, et al. Experimental study on lateral stiffness of lattice steel reinforced concrete middle frame with special-shaped columns [J]. Engineering Mechanice, 2013, 30(9): 34―46. (in Chinese)
