飞机撞击荷载计算模型中压溃力选取分析

韩鹏飞; 刘晶波; 陆新征; 林丽; 岑松

doi:10.6052/j.issn.1000-4750.2014.09.0808

飞机撞击荷载计算模型中压溃力选取分析

1.
清华大学土木水利学院土木工程系, 北京 100084;
2.
总参谋部工程兵科研三所, 河南, 洛阳 471023;
3.
清华大学航天航空学院工程力学系, 北京 100084

基金项目: 国家科技重大专项项目(2011ZX06002-10)

详细信息

作者简介:
韩鹏飞(1980-),男,山东人,工程师,博士生,主要从事爆炸震动隔离和结构抗冲击方面的研究(Email:feixuehan2003@sina.com);陆新征(1978-),男,安徽人,教授,博士,主要从事结构非线性计算和仿真研究(E-mail:luxz@tsinghua.edu.cn);林丽(1989-),女,广西人,硕士生,主要从事结构非线性计算和仿真研究(E-mail:l-lin07@mails.tsinghua.edu.cn);岑松(1972-),男,福建人,教授,博士,主要从事计算固体力学研究(E-mail:censong@tsinghua.edu.cn).

通讯作者:
刘晶波(1956-),男,辽宁人,教授,博士,主要从事结构抗震和防灾减灾研究(E-mail:liujb@tsinghua.edu.cn).

中图分类号: O313.4;TU312
计量
- 文章访问数: 397
- HTML全文浏览量: 19
- PDF下载量: 151
出版历程
- 收稿日期: 2014-09-22
- 修回日期: 2015-01-22
- 刊出日期: 2016-02-24

CRUSHING FORCE ANALYSIS OF A LOAD CALCULATION MODEL FOR AIRCRAFT IMPACT

1.
Department of Civil Engineering, School of Civil Engineering, Tsinghua University, Beijing 100084, China;
2.
The Third Research Institute of Engineering Corps, General Staff of PLA, Luoyang, Henan 471023, China;
3.
Department of Engineering Mechanics, School of Aerospace, Tsinghua University, Beijing 100084, China

More Information

Corresponding author:
LIU Jing-bo: 10.6052/j.issn.1000-4750.2014.09.0808

摘要

摘要: Riera提出的飞机撞击荷载计算模型是一种比较实用的简化模型,大多数研究在进行飞机撞击试验和数值模拟时通常会把试验结果和数值模拟结果与该模型的计算结果进行对比分析。通过介绍分析Riera模型,该模型中撞击荷载包括压溃力和惯性力两部分,因此模型的使用需要确定压溃力大小。为了合理使用Riera模型,梳理了现有压溃力计算公式,各公式给出的压溃力计算结果差别较大,并通过公式推导预测弹体的变形长度和撞击作用时间与试验数据进行对比分析,评价了现有压溃力计算公式,对更适宜于飞机撞击条件下的压溃力计算公式给出了说明,最后讨论了压溃力对撞击荷载曲线的影响,得出压溃力相对于惯性力不能被忽略,对撞击荷载影响较大的结论。
- 飞机撞击 /
- 理论分析 /
- 计算公式 /
- 压溃力 /
- 安全壳
Abstract: The Riera model is a simplified practical model for the calculation of aircraft impact load. The results of aircraft impact tests and numerical simulations are usually compared with the calculation results of this model in many studies. Since an impact load consists of a crushing force and an inertial force by introducing and analyzing this model, the crushing force is needed to be determined. In order to use the Riera model more reasonably, the existing formulas for crushing force calculations are summarized, but there is a great difference in the calculation results of crushing forces by using these formulas. And the comparison between the test data and calculation results by deformed length and impact time of projectile is also made to assess these formulas for crushing forces. The formulas, which are more suitable for crushing force calculation in aircraft impact cases, are given and the influence of crushing forces on impact loads is discussed. The crushing force should not be ignored with respect to inertial forces and it has a big influence on impact loads.
- aircraft impact /
- theoretical analysis /
- formulas /
- crushing force /
- containment

HTML全文

参考文献(24)

[1]	Riera J D. On the stress analysis of structures subjected to aircraft impact forces[J]. Nuclear Engineering and Design, 1968, 8(4):415-426.
[2]	Bignon P G, Riera J D. Verification of methods of analysis for soft missile Impact problems[J]. Nuclear Engineering and Design, 1980, 60(3):311-326.
[3]	Hornyik K. Analytic modeling of the impact of soft missiles on protective walls[C]. San Francisco:The 4th International Conference on Structural Mechanics in Reactor Technology, 1977(J7/3):1-12.
[4]	Bahar L Y, Rice J S. Simplified derivation of the reaction-time history in aircraft impact on a nuclear power plant[J]. Nuclear Engineering and Design, 1978, 49(3):263-268.
[5]	Wolf J P, Bucher, K M, Skrikerud P E. Response of equipment to aircraft impact[J]. Nuclear Engineering and Design, 1978, 47(1):169-193.
[6]	Abbas H, Paul D K, Godbole P N, et al. Soft missile impact on rigid targets[J]. International Journal of Impact Engineering, 1995, 16(5/6):727-737.
[7]	Arros J, Doumbalski N. Analysis of aircraft impact to concrete structures[J]. Nuclear Engineering and Design 2007, 237(12/13):1241-1249.
[8]	Daudeville L, Malécot Y. Concrete structures under impact[J]. European Journal of Environmental and Civil Engineering, 2011, 15(Suppl 1):101-140.
[9]	王远功. 飞射物对钢筋砼板碰撞的局部破坏及其设计评价公式[J]. 核科学与工程, 1994, 14(3):203-212. Wang Yuangong. The local damage and the design evaluation formulas of reinforced-concrete plates subjected to the impact of projectiles[J]. Chinese Journal of Nuclear Science and Engineering, 1994, 14(3):203-212. (in Chinese)
[10]	Sugano T, Tsubota H, Kasai Y, et al. Full-scale aircraft impact test for evaluation of impact force[J]. Nuclear Engineering and Design, 1993, 140(3):373-385.
[11]	Sugano T, Tsubota H, Kasai Y, et al. Local damage to reinforced concrete structures caused by impact of aircraft engine missiles Part 1. Test program, method and results[J]. Nuclear Engineering and Design, 1993, 140(3):387-405.
[12]	Sugano T, Tsubota H, Kasai Y, et al. Local damage to reinforced concrete structures caused by impact of aircraft engine missiles Part 2. Evaluation of test results[J]. Nuclear Engineering and Design, 1993, 140(3):407-423.
[13]	Lee K, Han S E, Hong J W. Analysis of impact of large commercial aircraft on a prestressed containment building[J]. Nuclear Engineering and Design, 2013, 265:431-449.
[14]	Thai D K, Kim S E, Lee H K. Effects of reinforcement ratio and arrangement on the structural behavior of a nuclear building under aircraft impact[J]. Nuclear Engineering and Design, 2014, 276:228-240.
[15]	Gerard G. The crippling strength of compression elements[J]. Journal of the Aerospace Science, 1958, 25(1):37-52.
[16]	Megson T H G. Aircraft structures for engineering students[M]. 4th ed. Oxford:Butterworth-Heinemann Press, 2007:303-320.
[17]	Alexander J M. An approximate analysis of the collapse of thin cylindrical shells under axial loading[J]. The Quarterly Journal of Mechanics and Applied Mathematics, 1960, 13(1):10-15.
[18]	Jones N. Structural impact[M]. England:Cambridge University Press, 1989:385-400.
[19]	Wierzbicki T, Bhat S U, Abramowicz W, et al. Alexander revisited-a two folding elements model of progressive crushing of tubes[J]. International Journal of Solids and Structures, 1992:29(24):3269-3288.
[20]	Abramowicz W, Jones N. Dynamic axial crushing of circular tubes[J]. International Journal of Impact Engineering, 1984, 2(3):263-281.
[21]	Jones N, Abramowicz W. Static and dynamic axial crushing of circular and square tubes[C]. Reid S R. Metal Forming and Impact Mechanics. New York:Pergamon Press, 1985:225-247.
[22]	Pugsley A, Macaulay M. The large-scale crumpling of thin cylindrical columns[J]. The Quarterly Journal of Mechanics & Applied Mathematics, 1960, 13(1):1-9.
[23]	Nachtsheim W, Stangenberg F. Selected results of Meppen slab tests-state of interpretation, comparison with computational investigations[C]. Chicago:The 7th International Conference on Structural Mechanics in Reactor Technology, 1983(J8/1):379-386.
[24]	Rüdiger E, Riech H. Experimental and theoretical investigations on the impact of deformable missiles onto reinforced concrete slabs[C]. Chicago:The 7th International Conference on Structural Mechanics in Reactor Technology, 1983(J8/3):387-394.
