肋板间距对开孔板连接件抗剪刚度影响分析

柳扬清; 刘玉擎; 郑双杰

doi:10.6052/j.issn.1000-4750.2015.02.0122

肋板间距对开孔板连接件抗剪刚度影响分析

同济大学桥梁工程系, 上海 200092

详细信息

作者简介:
柳扬清(1991-),男,吉林人,硕士生,主要从事组合结构桥梁研究(E-mail:lyq_solar@163.com);郑双杰(1985-),男,福建人,博士生,主要从事组合结构桥梁研究(E-mail:sjzhengcn@163.com).

通讯作者:
刘玉擎(1962-),男,江苏人,教授,博士,博导,主要从事组合结构桥梁研究(E-mail:yql@tongji.edu.cn).

中图分类号: U448.38
计量
- 文章访问数: 469
- HTML全文浏览量: 28
- PDF下载量: 143
出版历程
- 收稿日期: 2015-02-06
- 修回日期: 2015-05-31
- 刊出日期: 2016-09-24

ANALYSIS ON EFFECT OF PLATE SPACING ON SHEAR STIFFNESS OF PERFOBOND CONNECTORS

Department of Bridge Engineering, Tongji University, Shanghai 200092, China

More Information

Corresponding author:
LIU Yu-qing: 10.6052/j.issn.1000-4750.2015.02.0122

摘要

摘要: 为探讨开孔板连接件肋板间距合理的布置方法，通过模型试件抗剪推出试验和弹性地基梁理论，分析了肋板间距对开孔板连接件抗剪刚度的影响机理，提出了考虑肋板间距影响的开孔板连接件抗剪刚度计算公式。研究表明：肋板间距对开孔板连接件抗剪承载力及峰值滑移量影响较小，对开孔板连接件抗剪刚度影响较大；抗剪刚度随着肋板间距增加近似线性增大，逐渐趋近于单块开孔板连接件受力的抗剪刚度；肋板间距与开孔板孔径的比值为开孔板连接件抗剪刚度的主要影响因素，建议并列焊接多个开孔板连接件时距径比不宜小于3.3。
- 组合结构桥梁 /
- 开孔板连接件 /
- 模型试验 /
- 抗剪刚度 /
- 肋板间距
Abstract: In order to discuss the reasonable plate spacing of perfobond connector, the influence of plate spacing on the shear stiffness of perfobond connector is analyzed through the push-out model test and based on the theory of elastic foundation beam. The calculation formula for perfobond shear stiffness is proposed, which accounts for the influence of plate spacing. Research results indicate that the plate spacing has little effect on shear capacity and peak slip of perfobond connector but changes the shear stiffness. Shear stiffness approximately linearly increases as the plate spacing increases, gradually approaching the single plate shear stiffness. The main influence factor for the shear stiffness of perfobond connector is the spacing-diameter ratio, which is suggested to be no less than 3.3 when multi perfobonds are arranged in parallel.
- composite bridge /
- perfobond connector /
- model test /
- shear stiffness /
- plate spacing

HTML全文

参考文献(16)

[1]	刘玉擎, 裴炳志, 赵晨. 开孔板连接件在桥梁结构中的应用与发展[J]. 中外公路, 2009, 29(5): 112-116. Liu Yuqing, Pei Bingzhi, Zhao Chen. Application and development of perfobond connector in bridge structures[J]. Journal of China & Foreign Highway, 2009, 29(5): 112-116. (in Chinese)
[2]	He Jun, Liu Yuqing, Pei Bingzhi. Experimental study of the steel-concrete connection in hybrid cable-stayed bridges[J]. Journal of Performance of Constructed Facilities, 2014, 28(3): 559-570.
[3]	Ahn Jinhee, Lee Changoo, Won Jeonghun, Kim Sanghyo. Shear resistance of the perfobond-rib shear connector depending on concrete strength and rib arrangement[J]. Journal of Constructional Steel Research, 2010, 66(10): 1295-1307.
[4]	Kim Sanghyo, Choi Jaegu, Park Sejun, Ahn Jinhee , Jung Chiyoung, Behavior of composite girder with Y-type perfobond rib shear connectors[J]. Journal of Constructional Steel Research, 2014, 103(12): 275-289.
[5]	Vianna J da C, Andrade S A L de, Vellasco P C G da S, et al. Experimental study of Perfobond shear connectors in composite construction[J]. Journal of Constructional Steel Research, 2013, 81(2): 62-75.
[6]	Cândido-Martins J P S, Costa-Neves L F, S Vellasco P C G da. Experimental evaluation of the structural response of perfobond shear connectors[J]. Engineering Structures, 2010, 32(8): 1976-1985.
[7]	石宵爽, 王清远, 欧阳雯欣, 等. PBL剪力连接件粘结滑移性能的静载推出试验研究[J]. 工程力学, 2012, 29(1): 168-175. Shi Xiaoshuang, Wang Qingyuan, Ouyang Wenxin, et al. Push-out experimental study on bond-slip behaviors of PBL shear connector under static loading[J]. Engineering Mechanics, 2012, 29(1): 168-175. (in Chinese)
[8]	肖林, 强士中, 李小珍, 等. 考虑开孔钢板厚度的PBL剪力键力学性能研究[J]. 工程力学, 2012, 29(8): 282-288, 296. Xiao Lin, Qiang Shizhong, Li Xiaozhen, et al. Research on mechanical performance of PBL shear connectors considering the perforated plate's thickness[J]. Engineering Mechanics, 2012, 29(8): 282-288, 296. (in Chinese)
[9]	汪维安, 李乔, 赵灿晖, 等. 混合结构PBL剪力键的荷载-滑移特征曲线研究[J]. 工程力学, 2015, 32(3): 57-65, 81. Wang Weian, Li Qiao, Zhao Canhui, et al. Study on load-slip characteristic curve of perfobond shear connectors in hybrid structures[J]. Engineering Mechanics, 2015, 32(3): 57-65, 81. (in Chinese)
[10]	郑双杰, 刘玉擎. 开孔板连接件初期抗剪刚度试验[J]. 中国公路学报, 2014, 27(11): 69-75. Zheng Shuangjie, Liu Yuqing. Experiment of initial shear stiffness of perfobond connector[J]. China Journal of Highway and Transport, 2014, 27(11): 69-75. (in Chinese)
[11]	平陽兵, 古市耕輔, 山村正人, et al. 孔あき鋼板ジベルの基本特性に関する実験的研究[J]. コンクリート工学年次論文報告集, 1998, 20(3): 859-864. Taira Y, Furuichi K, Yamamura M, et al. Experimental research on fundamental characteristics of perfobond connectors[J]. Proceedings of the Japan Concrete Institute, 1998, 20(3): 859-864. (in Japanese)
[12]	古市耕輔, 平陽兵, 山村正人. 孔あき鋼板ジベルのせん断耐力に関する実験的研究[J]. 鹿島技術研究所年報, 1998, 46(9): 87-90. Furuichi K, Taira Y, Yamamura M. Experimental study on shear strength of shear connectors using perforated plate[J]. Annual Report of Kajima Technical Research Institute, 1998, 46(9): 87-90. (in Japanese)
[13]	保坂鐵矢, 光木香, 平城弘一, et al. 孔あき鋼板ジベルのせん断特性に関する実験的研究[J]. 構造工学論文集, 2000, 46A(3): 1593-1604. Hosaka T, Mitsuki K, Hiragi H, et al. An Experimental study on shear characteristics of perfobond strip and its rational strength equations[J]. Proceedings of Structural Engineering, 2000, 46A(3): 1593-1604. (in Japanese)
[14]	西海健二, 富永知德, 室井進次, et al. 拘束条件を考慮した孔あき鋼板ジベルのずれ止め特性に関する研究[J]. コンクリート工学年次論文報告集, 1998, 20(3): 865-870. Nishiumi K, Tominaga T, Muroi S, et al. Research on slip behavior of perfobond connectors under confinement[J]. Proceedings of the Japan Concrete Institute, 1998, 20(3): 865-870. (in Japanese)
[15]	堀元彦, 眞嶋隆行. 孔あき鋼板ジベルのせん断耐力および基本特性確認試験[J]. 日本橋梁技報, 2015(18): 8-15. Hori M, Majima T. Experimental study on shear capacity and fundamental characteristics of perfobond connector[J]. Journal of Japanese Bridge Technology, 2015(18): 8-15. (in Japanese)
[16]	日向優裕, 藤井堅, 深田和宏, et al. 並列配置された孔あき鋼板ジベルの終局ずれ挙動[J]. 構造工学論文集, 2007, 53A(3): 1089-1098. Himukai M, Fujii K, Fukada K, et al. Ultimate slip behavior of double-lined perfobond rib connector[J]. Proceedings of Structural Engineering, 2007, 53A(3): 1089-1098. (in Japanese)
