A SIMPLIFIED SIMULATION METHOD FOR PROGRESSIVE COLLAPSE OF REINFORCED CONCRETE SLABS
-
摘要: 楼板作为框架结构的重要组成构件,显著影响结构抗连续倒塌性能。该文提出了一种新的钢筋混凝土楼板简化数值模拟方法,把楼板沿两个平面方向离散形成一个梁网,每个方向上的网络线采用纤维梁单元来模拟钢筋和混凝土的组合受力行为。其中,采用T/L形截面的纤维梁单元模拟楼板边缘区域的梁板交界节点,以考虑楼板对梁在连续倒塌小变形下弯曲受力以及破坏形态的影响;采用矩形截面的纤维梁单元模拟楼板的中心区域,以考虑楼板在大变形下发挥的薄膜拉力。采用这种方法不仅解决了以往用壳单元模拟刚度过高的问题,还大大提高了整体结构的运算效率。该文对T/L形截面异形柱和单双向楼板试验分别进行模拟,结果表明该简化方法能够高效准确的模拟钢筋混凝土楼板的大变形力学行为,为整体结构的抗连续倒塌分析提供了有力的工具。Abstract: Floor slabs are important components of frame structures which largely affect the structural progressive collapse performance. This paper presents a simplified numerical simulation method for reinforced concrete (RC) slabs. A RC slab is discretized along two directions transferring into a beam network. The meshes at each direction are simulated by fiber beam elements to consider the composite mechanical behavior of steel reinforcement and concrete. In this method, beam-slab joints at the edge area of slabs are simulated by fiber beam elements with T/L sections, by which the effects of slabs on the bending behavior and the damage mode of the beams under small deformation in progressive collapse are considered. On the other hand, fiber beam elements with rectangle sections are used to simulate the interior area of slabs, by which the tensile membrane action of slabs under large deformation can be considered. This method can not only avoid the high stiffness problem when using shell elements, but also greatly improve the efficiency of the calculation of the whole structure. Finally, existing tests on special-shaped columns (T/L cross sections), one-way slabs and two-way slabs are simulated, respectively. The results show that the simplified method can efficiently and accurately simulate the reinforced concrete slabs under large deformation, providing a powerful tool for the simulation of progressive collapse analysis of whole structures.
-
-
[1] 梁益, 陆新征, 李易, 叶列平, 江见鲸. 楼板对结构抗连续倒塌能力的影响[J]. 四川建筑科学研究, 2010, 63(2): 5-10. Liang Yi, Lu Xinzheng, Li Yi, Ye Lieping, Jiang Jianjing. Influence of slabs on the progressive collapse behavior of structures[J]. Sichuan Building Science, 2010, 63(2): 5-10. (in Chinese) [2] 周育泷. 钢筋混凝土单向梁板子结构抗连续倒塌试验研究[D]. 烟台: 烟台大学, 2015. Zhou Yulong. An experimental study on the one-way reinforced concrete beam-slab substructures to resist progressive collapse[D]. Yantai: Yantai University, 2015. (in Chinese) [3] Qian Kai, Li Bing. Slab effects on response of reinforced concrete substructures after loss of corner column[J]. ACI Structural Journal, 2012, 109(6): 845-856. [4] Gillie M. Investigation of membrane flexure interaction in the Cardington slab at elevated temperatures[R]. Edinburg: PIT Project Research Report SS3, University of Edinburg, 2000. [5] Alashker Y, El-Tawil S, Sadek F. Progressive collapse resistance of steel-concrete composite floors[J]. Journal of Structural Engineering, 2010, 136(10): 1187-1196. [6] 李易. RC框架结构抗连续倒塌设计方法研究[D]. 北京: 清华大学, 2011. Li Yi. Study on design method for RC frame structures to resist progressive collapse[D]. Beijing: Tsinghua University, 2011. (in Chinese) [7] 梁益, 陆新征, 李易, 叶列平. 国外RC框架楼板抗连续倒塌设计方法的检验与分析[J]. 建筑结构, 2010, 40(2): 8-12. Liang Yi, Lu Xinzheng, Li Yi, Ye Lieping. Verification and analysis on foreign progressive-collapse-resistance design methods of RC frame structure[J]. Building Structure, 2010, 40(2): 8-12. [8] GB50010-2010, 混凝土结构设计规范[S]. 北京: 中国建筑工业出版社, 2010. GB50010-2010, Code for design of concrete structures[S]. Beijing: China Architecture & Building Press, 2010. (in Chinese) [9] 孙林柱. 钢筋混凝土异形柱轴心受压性能的试验研究[D]. 天津: 天津大学, 2006. Sun Linzhu. Experimental research of RC special-shaped columns under axial force[D]. Tianjin: Tianjin University, 2006. (in Chinese) [10] Shah A. Behavior of L-shaped reinforced concrete columns under combined biaxial bending and compression[D]. New Jersey: New Jersey Institute of Technology, 1984. [11] 陈礼刚. 钢筋混凝土板受火性能的试验研究[D]. 西安: 西安建筑科技大学, 2004. Chen Ligang. The experimental research of reinforced concrete slab[D]. Xi'an: Xi'an University of Architecture and Technology, 2004. (in Chinese) [12] Lim L, Wade C. Experimental fire tests of two-way concrete slabs[R]. New Zealand: Fire Engineering Research Report 02/12, University of Canterbury, 2002. -
