复杂载荷下油井管接头数值仿真平台的研发与应用

狄勤丰; 宋海涛; 陈锋; 王文昌; 张鹤; 靳泽中

doi:10.6052/j.issn.1000-4750.2016.03.S002

复杂载荷下油井管接头数值仿真平台的研发与应用

1.
上海大学, 上海市应用数学和力学研究所, 上海 200072;
2.
上海大学机电工程与自动化学院, 上海 200072

基金项目: 国家自然科学基金项目（U1663205，51174130）；上海市重点学科建设项目（S30106）；上海市优秀学术带头人项目（12XD1402500）；上海市部分地方院校能力建设项目（12160500200）；上海市力学在能源工程中的应用重点实验室开放基金项目（ORF-201602）；上海市教育委员会（高峰学科建设项目）；上海市青年科技英才扬帆计划项目（17YF1428000）

详细信息

作者简介:
狄勤丰(1963―),男,江苏人,教授,博士,主要从事石油工程力学问题的研究(E-mail:qinfengd@sina.com);宋海涛(1989―),男,江苏人,硕士生,主要从事有限元仿真分析工作(E-mail:892972506@qq.com);王文昌(1982―),男,甘肃人,讲师,博士,主要从事管柱力学方面的应用研究(E-mail:wangwenchang1982@163.com);张鹤(1989―),男,河北人,博士生,主要从事管柱力学研究(E-mail:crane_zhang@163.com);靳泽中(1989―),男,河南人,硕士生,主要从事有限元仿真分析工作(E-mail:jinzezhong@126.com).

通讯作者:
陈锋(1986―),男,浙江人,讲师,博士,主要从事有限元仿真计算的研究工作(E-mail:chenfeng536@126.com).

中图分类号: TE931.2
计量
- 文章访问数: 339
- HTML全文浏览量: 23
- PDF下载量: 56
出版历程
- 收稿日期: 2016-03-21
- 修回日期: 2016-11-24
- 刊出日期: 2017-06-24

THE DEVELOPMENT AND APPLICATION OF NUMERICAL PLATFORM FOR THREADED CONNECTIONS UNDER COMPLEX LOADS

1.
Shanghai Institute of Applied Mathematics and Mechanics, Shanghai University, Shanghai 200072, China;
2.
School of Mechatronics Engineering and Automation, Shanghai University, Shanghai 200072, China

摘要

摘要: 日益复杂的油气井钻采条件使得油井管柱面临越来越苛刻的载荷工况，油井管接头作为整个管柱的薄弱环节，其失效问题非常突出。实物实验费用昂贵、实验周期长，且复杂载荷工况难以施加，无法满足实际要求。该文基于油井管接头三维全尺寸弹塑性有限元分析，构建了复杂载荷下油井管接头数值仿真平台，是实物实验的一个有力补充。该仿真平台所得极限工作扭矩与API标准提供数据基本吻合（零轴向力条件下），同时具有分析复杂工况条件下油井管接头三维力学特性的能力。通过该仿真平台，能很好地描述复杂载荷作用下油井管接头的受力特征，快速、全面地评估复杂载荷作用下油井管接头的连接强度和密封性能，明确油井管接头的极限载荷工况。
- 油井管接头 /
- 复杂载荷 /
- 三维力学分析 /
- 有限元方法 /
- 仿真平台
Abstract: With the exploration of oil and gas sources moves further to greater depths and into harsher environments, the working condition of pipe string becomes increasingly severe. As the weakest part of the string, the failure of threaded connections occurs frequently. Full-scale experiments are costly, time consuming and complex loads are difficult to apply. Based on three-dimensional elasto-plastic finite element analysis, a numerical platform for threaded connections is developed, which is a powerful complement to physical experiments. The calculated ultimate working torque of threaded connections by the numerical platform is consistent with the data in API standard (without axial tension). Furthermore, the numerical platform can be used to analyze the three-dimensional mechanical properties of threaded connections under complex loads. The numerical platform can evaluate the structural and sealing integrity of threaded connections accurately, and determine the load limits of threaded connections.
- threaded connections /
- complex loads /
- three-dimensional mechanical analysis /
- finite element method /
- numerical platform

HTML全文

参考文献(10)

[1]	蔡晓闻, 高连新. 我国油套管特殊螺纹接头的发展现状[J]. 焊管, 2008, 31(4): 41―44. Cai Xiaowen, Gao Lianxin. Current development situation of the special thread connection for Tubing/Casing [J]. Welded Pipe and Tube, 2008, 31(4): 41―44. (in Chinese)
[2]	李斌, 杨智春, 于哲峰. 钻柱接头扣型改进设计的有限元分析[J]. 机械强度, 2006, 28(5): 721―724. Li Bin, Yang Zhichun, Yu Zhefeng. Finite element analysis of improving designs for a drill string joint [J]. Journal of Mechanical Strength, 2006, 28(5): 721―724. (in Chinese)
[3]	Hilbert L B, Kalil I A. Evaluation of premium threaded connections using finite-element analysis and full-scale testing [C]. SPE/IADC Drilling Conference, New Orleans, Louisiana, 1992: 23904.
[4]	林元华, 施太和, 姚振强, 等. 钻具螺纹接头力学性能计算方法及其应用[J]. 上海交通大学学报, 2005, 39(7): 1058―1062. Lin Yuanhua, Shi Taihe, Yao Zhenqiang, et al. A model to compute the mechanical property of drillpipe tool joint and its application [J]. Journal of Shanghai Jiao Tong University, 2005, 39(7): 1058―1062. (in Chinese)
[5]	李再均, 鲜奇飚, 张兴超, 等. 双台肩钻具接头台肩距离的数值模拟和力学测试[J]. 石油矿场机械, 2012, 41(4): 47―52. Li Zaijun, Xian Qibiao, Zhang Xingchao, et al. Numerical simulation and mechanical property test of double shoulder tool joint [J]. Oil Field Equipment, 2012, 41(4): 47―52. (in Chinese)
[6]	狄勤丰, 陈锋, 王文昌, 等. 双台肩钻杆接头三维力学分析[J]. 石油学报, 2012, 33(5): 871―877. Di Qinfeng, Chen Feng, Wang Wenchang, et al. Three-dimensional mechanical analysis of the double-shouldered tool joint [J]. Acta Petrolei Sinica, 2012, 33(5): 871―877. (in Chinese)
[7]	API, API RP 7G: Recommended practice for drill stem design and operating limits [S]. 16th ed. 1998.
[8]	Benzley S E, Perry E, Merkley K, et al. A comparison of all hexagonal and all tetrahedral finite element meshes for elastic and elasto-plastic analysis [C]. Proceedings, 4th International Meshing Roundtable, Sandia National Laboratories Albuquerque, NM, 1995: 1―13.
[9]	祝效华, 董亮亮, 童华, 等. 拉弯复合载荷作用下的API短圆套管螺纹力学行为[J]. 石油学报, 2013, 34(1): 157―163. Zhu Xiaohua, Dong Liangliang, Tong Hua, et al. Mechanical behaviors of short-round thread of the API casing under combined load of stretching and bending moment [J]. Acta Petrolei Sinica, 2013, 34(1): 157―163. (in Chinese)
[10]	许志倩, 闫相祯, 杨秀娟. 非API套管接头完整性评估计算方法[J]. 工程力学, 2016, 33(2): 188―199. Xu Zhiqian, Yan Xiangzhen, Yang Xiujuan, et al. Integrity evaluation method for non-API casing connetions [J]. Engineering Mechanics, 2016, 33(2): 188―199. (in Chinese)
