分离双扁平箱梁气动力干扰效应研究

李少杰; 刘小兵; 杨群; 刘庆宽; 马文勇

doi:10.6052/j.issn.1000-4750.2016.03.S008

分离双扁平箱梁气动力干扰效应研究

李少杰¹,
刘小兵^2,3,,
杨群¹,
刘庆宽^2,3,
马文勇^2,3

1.
石家庄铁道大学土木工程学院, 石家庄 050043;
2.
石家庄铁道大学大型结构健康诊断与控制研究所, 石家庄 050043;
3.
河北省大型结构健康诊断与控制重点实验室, 石家庄 050043

基金项目: 国家自然科学基金项目（51308359）；河北省高等学校科学技术研究基金项目（QN20131169，QN2015213）

详细信息

作者简介:
李少杰(1990―),男,河北人,硕士生,主要从事桥梁抗风研究(E-mail:li_shao_jie_123@163.com);杨群(1981―),女,湖南人,讲师,硕士,从事桥梁工程研究(E-mail:quny123@126.com);刘庆宽(1971―),男,河北人,教授,博士,博导,主要从事桥梁与结构的风荷载、风致振动与控制研究(E-mail:lqk@stdu.edu.cn);马文勇(1981―),男,陕西人,副教授,博士,主要从事结构抗风研究(E-mail:mawenyong@126.com).

通讯作者:
刘小兵(1982―),男,湖南人,副教授,博士,主要从事桥梁的风致振动与控制研究(E-mail:x_b_liu@126.com).

中图分类号: U441+;U446
计量
- 文章访问数: 241
- HTML全文浏览量: 19
- PDF下载量: 31
出版历程
- 收稿日期: 2016-03-28
- 修回日期: 2017-01-06
- 刊出日期: 2017-06-24

STUDY ON INTERFERENCE EFFECT OF AERODYNAMIC FORCE OF TWIN SEPARATE FLAT BOX GIRDERS

1.
School of Civil Engineering, Shijiazhuang Tiedao University, Shijiazhuang 050043, China;
2.
Structure Health Monitoring and Control Institute, Shijiazhuang Tiedao University, Shijiazhuang 050043, China;
3.
Key Laboratory of Structural Health Diagnosis and Control of Hebei Province, Shijiazhuang 050043, China

摘要

摘要: 通过节段模型风洞试验研究了分离双扁平箱梁气动力的干扰效应，得到了气动力系数干扰因子随间距的变化曲线。研究结果表明：上游箱梁阻力系数的干扰效应不明显，下游箱梁阻力系数的干扰效应在D/B≥2（D/B为双箱梁的净间距与单幅箱梁宽之比）时基本可以忽略，在D/B < 2时为减小效应，间距越小，减小效应越显著；下游箱梁升力系数的干扰效应不明显，上游箱梁升力系数的干扰效应在D/B≥2时基本可以忽略，在D/B < 2时为减小效应。
- 分离双扁平箱梁 /
- 风洞试验 /
- 气动力系数 /
- 干扰效应 /
- 间距
Abstract: The interference effect of aerodynamic forces of twin separate flat box girders were investigated by wind tunnel tests of sectional models. The interference-factor changing curves of aerodynamic coefficients versus separate distance were obtained. The research results show that the interference effect of drag coefficient of a forward box girder is slight. The interference effect of drag coefficient of a leeward box girder can be neglected when D/B≥2 and can be recognized as a reducing effect when D/B< 2. This reducing effect is more remarkable for a small distance. The interference effect of lift coefficient of a leeward box girder is slight. The interference effect of lift coefficient of a forward box girder can be neglected when D/B≥2 and can be recognized as a reducing effect when D/B< 2.
- twin separate flat box girder /
- wind tunnel test /
- aerodynamic coefficient /
- interference effect /
- distance

HTML全文

参考文献(10)

[1]	Irwin R A, Stoyanoff S, Xie J, et al. Tacoma Narrows 50 years later-wind engineering investigations for parallel bridges [J]. Bridge Structures: Assessment, Design and Construction, 2005, 1(1): 3―17.
[2]	Ju-won Seo, Ho-Kyung Kim, Jin Park, et al. Interference effect on vortex-induced vibration in a parallel twin cable-stayed bridge [J]. Journal of Wind Engineering Hand Industrial Aerodynamics, 2013, 116(116): 7―20.
[3]	Kimura K, Shima K, Sano K, et al. Effects of separation distance on wind-induced response of parallel box girders [J]. Journal of Wind Engineering and Industrial Aerodynamics, 2008, 96(6): 954―962.
[4]	朱乐东, 周奇, 郭震山, 等. 箱形双幅桥气动干扰效应对颤振和涡振的影响[J]. 同济大学学报, 2010, 38(5): 632―638. Zhu Ledong, Zhou Qi, Guo Zhenshan, et al. Aerodynamic interference effects on flutter and vortex-excited resonance of bridges with twin-separate parallel box decks [J]. Journal of Tongji University (Natural Science), 2010, 38(5): 632―638. (in Chinese)
[5]	刘小兵, 杨群. 双幅典型断面静力系数气动干扰试验研究[J]. 工程力学, 2012, 29(增刊II): 107―112. Liu Xiaobing Yang Qun. Experimental study on aerodynamic interference on aerostatic coefficients of twin representative section [J]. Engineering Mechanics, 2012, 29(Suppl II): 107―112. (in Chinese)
[6]	陈政清, 刘小兵, 刘志文. 双幅桥面桥梁三分力系数的气动干扰效应研究[J]. 工程力学, 2008, 25(7): 87―93. Chen Zhengqing, Liu Xiaobing, Liu Zhiwen. Study of aerodynamic interference effects on aerodynamic coefficients of twin-deck bridges [J]. Engineering Mechanics, 2008, 25(7): 87―93. (in Chinese)
[7]	陈政清, 牛华伟, 刘志文. 双幅桥面桥梁主梁气动干扰效应研究[J]. 桥梁建设, 2007, 25(6): 9―12. Chen Zhengqing, Niu Huawei, Liu Zhiwen. Study of aerodynamic interference effect on main girders of twin-deck bridges [J]. Bridge Construction, 2007, 25(6): 9―12. (in Chinese)
[8]	刘志文, 陈政清, 刘高. 双幅桥面桥梁三分力系数气动干扰效应试验研究[J]. 湖南大学学报, 2008, 35(1): 16―20. Liu Zhiwen, Chen Zhengqing, Liu Gao. Experimental study of aerodynamic interference effects on aerostatic coefficients of twin decks bridges [J]. Journal of Hunan University, 2008, 35(1): 16―20. (in Chinese)
[9]	曲慧, 马如进, 陈艾荣. 分离式钝体钢箱梁静气动力节段风洞试验研究[J]. 结构工程师, 2010, 26(3): 89―94. Qu Hui, Ma Rujin, Chen Airong. Study on static aerodynamic force of separate steel box-girder with bluff body via wind tunnel test of sectional model [J]. Structural Engineers, 2010, 26(3): 89―94. (in Chinese)
[10]	郭震山, 孟晓亮, 周奇, 朱乐东．既有桥梁对邻近新建桥梁三分力系数的气动干扰效应[J]. 工程力学, 2010, 27(9): 181―186. Guo Zhenshan, Meng Xiaoliang, Zhou Qi, Zhu Ledong. Aerodynamic interferences of an existed bridge on aerodynamic coefficients of an adjacent new bridge [J]. Engineering Mechanics, 2010, 27(9): 181―186. (in Chinese)
