基于临界应力强度因子的胶接对接接头抗拉强度简便预测方法

李戎; 梁斌; NODA Nao-Aki

doi:10.6052/j.issn.1000-4750.2016.06.0497

基于临界应力强度因子的胶接对接接头抗拉强度简便预测方法

1.
河南科技大学土木工程学院, 河南, 洛阳 471023;
2.
九州工业大学机械系, 日本, 北九州市 804-8550

基金项目: 国家自然科学基金项目（51105132，11402077）

详细信息

作者简介:
李戎(1986―),女,河北人,讲师,博士,主要从事工程结构强度、复合结构应力解析研究(E-mail:lirongxb@163.com);NODA Nao-Aki(1956―),男,日本人,教授,博士,博导,主要从事特殊形状/材料、复合结构的应力解析研究(E-mail:noda@mech.kyutech.ac.jp).

通讯作者:
梁斌(1963―),男,河南人,教授,博士,博导,主要从事工程结构强度、稳定性及优化设计研究(E-mail:liangbin4231@163.com).

中图分类号: TG495;TG494.2
计量
- 文章访问数: 381
- HTML全文浏览量: 16
- PDF下载量: 42
出版历程
- 收稿日期: 2016-06-27
- 修回日期: 2017-04-24
- 刊出日期: 2017-11-24

A CONVENIENT ADHESIVE STRENGTH PREDICTION METHOD FOR ADHESIVE BUTT JOINT IN TERMS OF THE CRITICAL STRESS INTENSITY FACTOR

1.
College of Civil Engineering, Henan University of Science and Technology, Luoyang, Henan 471023, China;
2.
Department of Mechanical Engineering, Kyushu Institute of Technology, Kitakyushu-shi 804-8550, Japan

摘要

摘要: 为了能够对胶接对接接头进行抗拉强度预测，该文以有限元分析方法为基础，通过利用参考问题的无量纲应力强度因子、接头模型与参考问题模型之间应力值的比值以及接头抗拉强度的试验数值，得到了胶接对接接头的临界应力强度因子数值，从而提出了一个基于临界应力强度因子的胶接对接接头抗拉强度的简便预测新方法。该方法能够在保证精确度的基础上快速计算出胶接对接接头的应力强度因子，通过使用任意某一胶层厚度时的抗拉强度试验数值预测出其他胶层厚度时对接接头的抗拉强度数值。通过三种胶接对接接头的算例对比分析，证明了该方法的预测结果与实际结果非常接近，预测精度良好，便于工程应用。
- 胶接对接接头 /
- 粘结抗拉强度预测 /
- 有限元分析方法 /
- 临界应力强度因子 /
- 胶层厚度
Abstract: For the purpose of predicting the tensile strength for adhesive butt joint, a convenient adhesive strength prediction method is presented in terms of the critical stress intensity factor. Based on the finite element method and adhesive tensile strength, the critical stress intensity factor can be obtained conveniently and accurately since the reference problem has exact solutions. Then, a new prediction method for the adhesive butt joint is proposed based on the conclusion that the critical stress intensity factor is almost independent of the adhesive thickness. In this paper, the predicted adhesive strengths for adhesive butt joints with different adhesive thicknesses can be obtained conveniently by using only one arbitrary reference tensile strength. To verify the correctness of this method, the measured and predicted adhesive tensile strength for adhesive butt joints with three kinds of material combinations are analyzed. The calculation results indicated that the predicted results coincide with the experimental results. The validity and usefulness of the proposed method in engineering application is proved.
- adhesive butt joint /
- adhesive tensile strength prediction /
- finite element method /
- critical stress intensity factor /
- adhesive thickness

HTML全文

参考文献(21)

[1]	Naito K, Onta M, Kogo Y. The effect of adhesive thickness on tensile and shear strength of polyimide adhesive[J]. International Journal of Adhesion and Adhesives, 2012, 36:77-85.
[2]	Liu Z X, Huang Y A, Yin Z P, Bennati S, Valvo P S. A general solution for the two-dimensional stress analysis of balanced and unbalanced adhesively bonded joints[J]. International Journal of Adhesion and Adhesives, 2014, 54:112-123.
[3]	赵波, 吕振华, 吕毅宁. 基于理论解的三种胶接接头简化有限元单元[J]. 工程力学, 2010, 27(7):1-9. Zhao Bo, Lü Zhenhua, Lü Yining. Enforcing of a theoretical solution of three adhesive joints into simplified finite element formulations for stiffness prediction[J]. Engineering Mechanics, 2010, 27(7):1-9. (in Chinese)
[4]	Huang Z, Kumar P, Dutta I, Pang J H L, Sidhu R. A general methodology for calculating mixed mode stress intensity factors and fracture toughness of solder joints with interfacial cracks[J]. Engineering Fracture Mechanics, 2014, 131:9-25.
[5]	Kitasako Y, Burrow M F, Nikaido T, Harada N, Inokoshi S, Yamada T, Takatsu T. Shear and tensile bond testing for resin cement evaluation[J]. Dental Materials, 1995, 11(5/6):298-304.
[6]	Hattori T, Sakata S, Hatsuda T, Murakami G. A stress singularity parameter approach for evaluating adhesive strength[J]. JSME International Journal. Series 1, Solid Mechanics, Strength of Materials, 1988, 31(4):718-723.
[7]	Stazi F, Giampaoli M, Rossi M, Munafò P. Environmental ageing on GFRP pultruded joints:Comparison between different adhesives[J]. Composite Structures, 2015, 133:404-414.
[8]	Afendi M, Majid M S A, Daud R, Rahman A A, Teramoto T. Strength prediction and reliability of brittle epoxy adhesively bonded dissimilar joint[J]. International Journal of Adhesion and Adhesives, 2013, 45(2):21-31.
[9]	Ikegami K, Kajiyama M, Kamiko S, Shiratori E. Experimental studies of the strength of an adhesive joint in a state of combined stress[J]. The Journal of Adhesion, 1979, 10(1):25-38.
[10]	Suzuki Y. Adhesive tensile strengths of scarf and butt joints of steel plates (Relation between adhesive layer thicknesses and adhesive strengths of joints)[J]. JSME International Journal, 1987, 30(265):1042-1051.
[11]	Akisanya A R, Meng C S. Initiation of fracture at the interface corner of bi-material joints[J]. Journal of the Mechanics and Physics of Solids, 2003, 51(1):27-46.
[12]	Mintzas A, Nowell D. Validation of an H_cr-based fracture initiation criterion for adhesively bonded joints[J]. Engineering Fracture Mechanics, 2012, 80:13-27.
[13]	Qian Z, Akisanya A R. An experimental investigation of failure initiation in bonded joints[J]. Acta Materialia, 1998, 46(14):4895-4904.
[14]	Reedy E D Jr, Guess T R. Interface corner failure analysis of joint strength:Effect of adherend stiffness[J]. International Journal of Fracture, 1997, 88(4):305-314.
[15]	He X C. A review of finite element analysis of adhesively boned joints[J]. International Journal of Adhesion and Adhesives, 2011, 31(4):248-264.
[16]	熊波, 罗锡林, 谭惠丰. 考虑接头作用的全复合材料桁架结构多尺度分析[J]. 工程力学, 2015, 32(8):229-235. Xiong Bo, Luo Xilin, Tan Huifeng. Multi-scale analysis of all-composite truss considering joint effects[J]. Engineering Mechanical, 2015, 32(8):229-235. (in Chinese)
[17]	周一波, 李晓叶, 王效贵. 压电与导体双材料界面端的奇异性研究[J]. 工程力学, 2014, 31(8):209-216. Zhou Yibo, Li Xiaoye, Wang Xiaogui. Singularities in the wedge of piezoelectric media and conductor[J]. Engineering Mechanics, 2014, 31(8):209-216. (in Chinese)
[18]	Bogy D B. Edge-bonded dissimilar orthogonal elastic wedges under normal and shear loading[J]. Journal of Applied Mechanics, 1968, 35(3):460-466.
[19]	Bogy D B. Two edge-bonded elastic wedges of different materials and wedge angles under surface tractions[J]. Journal of Applied Mechanics, 1971, 38(2):377-386.
[20]	Zhang Y, Noda N A, Wu P Z, Duan M L. A mesh-independent technique to evaluate stress singularities in adhesive joints[J]. International Journal of Adhesion and Adhesives, 2015, 57:105-117.
[21]	Noda N A, Shirao R, Li J, Sugimoto J S. Intensity of singular stress fields causing interfacial debonding at the end of a fiber under pullout force and transverse tension[J]. International Journal of Solids Structures, 2007, 44(13):4472-4491.
