COMPARISON OF DYNAMIC AMPLIFICATION FACTORS CALCULATED FROM BRIDGE STRAIN AND DEFLECTION
-
摘要: 比较了简支梁桥和连续梁桥的应变和挠度动力放大系数的大小关系。首先对作用有移动常量力的简支梁和连续梁进行理论推导，分别得到了应变和挠度动力放大系数并进行了比较。为考虑动力车辆荷载影响，采用移动弹簧质量作为车辆模型建立了车桥耦合振动模型进行数值模拟。理论推导和数值模拟的结果均表明：应变动力放大系数基本小于挠度动力放大系数；两者比值受很多因素影响，其中计算桥梁响应所用的桥梁模态阶数对比值的影响较大。Abstract: A comparison of dynamic amplification factors calculated from bridge strain and deflection of a simply-supported beam and a continuous beam is conducted. Firstly, the strain and deflection dynamic amplification factors are theoretically derived and compared based on a simply-supported beam and a continuous beam under the action of a constant moving force. To consider the effect of dynamic vehicle loading, numerical simulations are performed using a developed vehicle-bridge coupled model while adopting a moving spring mass vehicle model. The results from both the theoretical analysis and numerical simulation show that the strain dynamic amplification factor is less than the deflection dynamic amplification factor and that their ratio is influenced by a number of factors, among which the number of vibration modes used in calculating the bridge responses has a significant influence.
-
Keywords:
- vehicle-bridge interaction /
- dynamic amplification factor /
- simulation /
- strain /
- deflection
-
-
[1] Deng L, Yu Y, Zou Q, et al. State-of-the-art review of dynamic impact factors of highway bridges[J]. Journal of Bridge Engineering, 2014, doi:10.1061/(ASCE)BE. 1943-5592.0000672, 04014080. [2] Majka M, Hartnett M. Effects of speed, load and damping on the dynamic response of railway bridges and vehicles[J]. Computers and Structures, 2008, 86(6):556-572. [3] Huang D. Dynamic analysis of steel curved box girder bridges[J]. Journal of Bridge Engineering, 2001, 6(6):506-513. [4] Li H, Wekezer J, Kwasniewski L. Dynamic response of a highway bridge subjected to moving vehicles[J]. Journal of Bridge Engineering, 2008, 13(5):439-448. [5] Yu Y, Deng L, Wang W, et al. Local impact analysis for deck slabs of prestressed concrete box-girder bridges subject to vehicle loading[J]. Journal of Vibration and Control, 2015, doi: 10.1177/1077546315575434. [6] 李忠献, 陈锋. 曲线箱梁桥的车桥相互作用分析[J]. 工程力学, 2007, 24(11):93-99.
Li Zhongxian, Chen Feng. Analysis of interaction between vehicle and bridge with curved box girder[J]. Engineering Mechanics, 2007, 24(11):93-99. (in Chinese)[7] Fafard M, Laflamme M, Savard M, et al. Dynamic analysis of existing continuous bridge[J]. Journal of Bridge Engineering, 1998, 3(1):28-37. [8] Aluri S, Jinka C, Gangarao H V S. Dynamic response of three fiber reinforced polymer composite bridges[J]. Journal of Bridge Engineering, 2005, 10(6):722-730. [9] 周勇军, 蔡军哲, 石雄伟, 等. 基于加权法的桥梁冲击系数计算方法[J]. 交通运输工程学报, 2013, 13(4):29-36.
Zhou Yongjun, Cai Junzhe, Shi Xiongwei, et al. Computing method of bridge impact factor based on weighted method[J]. Journal of Traffic and Transportation Engineering, 2013, 13(4):29-36. (in Chinese)[10] Chang D, Lee H. Impact factors for simple-span highway girder bridges[J]. Journal of Structural Engineering, 1994, 120(3):704-715. [11] Conte J P. Random vibration analysis of dynamic vehicle-bridge interaction due to road unevenness[J]. Journal of Engineering Mechanics, 2012, 138(7):816-825. [12] Zou Q, Deng L, Guo T, et al. Comparative study of different numerical models for vehicle-bridge interaction analysis[J]. International Journal of Structural Stability and Dynamics, 2016, 16(9):1636-1643. [13] Ding L, Hao H, Zhu X. Evaluation of dynamic vehicle axle loads on bridges with different surface conditions[J]. Journal of Sound and Vibration, 2009, 323(3/4/5):826-848. [14] 邓露, 王维. 公路桥梁动力冲击系数研究进展[J]. 动力学与控制学报, 2016, 14(4):289-300.
Deng Lu, Wang Wei. Research progress on dynamic impact factors of highway bridges[J]. Journal of Dynamics and Control, 2016, 14(4):289-300. (in Chinese)[15] Kirkegaard P H, Nielsen S R K, Enevoldsen I. Heavy vehicles on minor highway bridges-calculation of dynamic impact factors from selected crossing scenarios[R]. Paper No172. Aalborg, Denmark:Dept. of Building Technology and Structural Engineering, Aalborg Univ., 1997:1-19. [16] 邓建良, 吴定俊, 李奇. 简支梁桥动力系数的移动荷载列分析[J]. 工程力学, 2012, 29(10):177-183.
Deng Jianliang, Wu Dingjun, Li Qi. Dynamic factor analysis of simple-supported bridges using discrete moving load model[J]. Engineering Mechanics, 2012, 29(10):177-183. (in Chinese)[17] Shi X, Cai C S, Chen S. Vehicle induced dynamic behavior of short-span slab bridges considering effect of approach slab condition[J]. Journal of Bridge Engineering, 2008, 13(1):83-92. [18] Xu Y L, Li Q, Wu D J, et al. Stress and acceleration analysis of coupled vehicle and long-span bridge systems using the mode superposition method[J]. Engineering Structures, 2010, 32(5):1356-1368. [19] Xia H, Zhang N, Guo W W. Analysis of resonance mechanism and conditions of train-bridge system[J]. Journal of Sound and Vibration, 2006, 297(3/4/5):810-822. -
