基于DDD离心加载法的黑山铁矿西帮边坡稳定性研究

刘欣欣, 唐春安, 龚斌, 于庆磊

刘欣欣, 唐春安, 龚斌, 于庆磊. 基于DDD离心加载法的黑山铁矿西帮边坡稳定性研究[J]. 工程力学, 2018, 35(1): 191-200. DOI: 10.6052/j.issn.1000-4750.2016.09.0726
引用本文: 刘欣欣, 唐春安, 龚斌, 于庆磊. 基于DDD离心加载法的黑山铁矿西帮边坡稳定性研究[J]. 工程力学, 2018, 35(1): 191-200. DOI: 10.6052/j.issn.1000-4750.2016.09.0726
shu
LIU Xin-xin, TANG Chun-an, GONG Bin, YU Qing-lei. RESEARCH ON THE STABILITY OF THE WEST SLOPE OF THE HEISHAN IRON MINE BASED ON THE DDD CENTRIFUGAL LOADING METHOD[J]. Engineering Mechanics, 2018, 35(1): 191-200. DOI: 10.6052/j.issn.1000-4750.2016.09.0726
Citation: LIU Xin-xin, TANG Chun-an, GONG Bin, YU Qing-lei. RESEARCH ON THE STABILITY OF THE WEST SLOPE OF THE HEISHAN IRON MINE BASED ON THE DDD CENTRIFUGAL LOADING METHOD[J]. Engineering Mechanics, 2018, 35(1): 191-200. DOI: 10.6052/j.issn.1000-4750.2016.09.0726
shu

基于DDD离心加载法的黑山铁矿西帮边坡稳定性研究

  • 1.

    东北大学岩石破裂与失稳研究中心, 沈阳 110004;

  • 2.

    大连理工大学土木与水利学院, 辽宁, 大连 116024

基金项目: 国家重点基础研究发展计划（973）项目（2014CB047100）；国家自然科学基金项目（51579031，51628401）
详细信息
    作者简介:

    刘欣欣(1991-),女,黑龙江哈尔滨人,硕士,主要从事岩石力学与工程方面的研究工作(E-mail:1193566434@qq.com);龚斌(1990-),男,陕西铜川人,博士生,主要从事岩土工程稳定性分析方面的研究工作(E-mail:bingong@foxmail.com);于庆磊(1981-),男,山东泰安人,教授,博士,从事岩石力学数值方法与裂隙岩体破裂机制研究(E-mail:yuqinglei@mail.neu.edu.cn).

    通讯作者:

    唐春安(1958-),男,湖南黔阳县人,特聘教授、博士,博导,主要从事岩石破裂与失稳方面的教学与研究工作(E-mail:tca@mail.neu.edu.cn).

  • 中图分类号: U443.15

RESEARCH ON THE STABILITY OF THE WEST SLOPE OF THE HEISHAN IRON MINE BASED ON THE DDD CENTRIFUGAL LOADING METHOD

  • 1.

    Center for Rock Instability & Seismicity Research, Northeastern University, Shenyang 110004, China;

  • 2.

    School of Civil and Hydraulic Engineering, Dalian University of Technology, Dalian, Liaoning 116024, China

HTML全文

    摘要
  • 摘要: 非连续变形与位移分析方法（DDD）是一种新的岩石破坏全过程分析方法，该方法有效的结合了RFPA有限元方法及非连续变形分析（DDA）方法的优势，解决了有限元不能很好地进行大位移动态分析及DDA不能模拟岩石中新破裂的萌生、扩展过程的问题，真实再现了边坡由细观裂纹的演化直至宏观破坏的全过程。在原有的DDD方法的基础上，结合了传统的离心加载试验机理，形成了全新的DDD离心加载法。该方法不仅保存了DDD方法原有的计算特点，且实现了不用预先假定滑移面而是通过计算得出其滑移失稳面，更加符合工程实际。基于改进的DDD离心加载法，结合黑山铁矿西帮边坡给出的剖面及要进行崩落开采的实际工况，建立了二维的含有采空区的边坡稳定性分析模型。模拟了在有无锚索作用下的含有采空区边坡的滑移机理并进行了对比分析，分别分析了有无锚索作用下的含有采空区边坡由细观裂纹的演化直至宏观破坏的剪应力变化过程、安全系数、竖向及水平位移矢量的变化。结果表明：采空区外凸棱角区是边坡应力集中的关键点，边坡的失稳破坏过程有明显的张拉作用，与实际提供的工况现场取得了较好的一致性。锚索虽将断层以上坡体应力集中形态有效分散提高了边坡的安全系数、使得各向位移矢量的变化明显减小，但黑山西帮边坡仍然存在潜在滑移的可能，仍需后续的继续观测。
    Abstract: Discontinuous deformation and displacement analysis (DDD) is a new way for analyzing the slope failure process, and this method combines the advantage of finite element method of RFPA and discontinuous deformation analysis (DDA) effectively. The problems such as large displacements which cannot be analyzed by RFPA, by the fractured rock initiation, and by propagation process issues which cannot be simulated by DDA, can be solved by DDD. And it also revealed the whole production process of the microscopic crack of the slope until it is destructed. Based on the original method of DDD and conventional centrifugal load test mechanism, it has been converted into a new formation called DDD centrifugal loading. This method not only preserves the feature of the original DDD, but also attains the instability sliding surface of the slope. Based on the DDD centrifugal loading method, the sectional slope of west slope of the Heishan Iron Mine and determination of caving in actual working conditions that establish a two-dimensional model of the slope with hole. It simulated mechanism of the sliding slope with hole under the presence or absence of the anchor and it also analyzed the evolution of the shear process from microscopic cracks to macroscopic damage, the safety factor and the vertical and horizontal displacement vector. The results show that:the caving hole of the convex corners area of the slope is a key point of stress concentration, and there is a significant effect of tension on slope instability and failure process which got a good agreement with the actual provision of the slope. Although the anchor disperses stress concentration effectively, improves the safety factor of the slope, and reduce the displacement, it still has the possibility of destruction and need to observe continuously.
    • HTML全文
    • 参考文献(17)
  • [1] 郑颖人, 赵尚毅, 邓卫东, 等. 岩质边坡破坏机制有限数值模拟分析[J]. 岩石力学与工程学报, 2003, 22(12):1943-1952. Zheng Yingren, Zhao Shangyi, Deng Weidong, et al. Numerical simulation on failure mechanismof rock slope by strength reduction FEM[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(12):1943-1952. (in Chinese)
    [2] 王金龙, 王培涛, 杨天鸿, 等. 黑山铁矿挂帮回采对西加固边坡岩体的扰动模式[J]. 金属矿山, 2012, 432(6):1-8. Wang Jinlong, Wang Peitao, Yang Tianhong, et al. Reinforced slope rock mass disturbance mode on mining hanging-wall ore in Heishan open-pit mine[J].Metal Mine, 2012, 432(6):1-8. (in Chinese)
    [3] 朱彦鹏, 李京榜叶帅华, 等. 基于锚索格构梁支护结构的高边坡健康监测研究与分析[J]. 工程力学, 2015, 32(增刊):271-276, 283. Zhu Yanpeng, Li Jingbang, Ye Shuaihua, et al. Health monitoring and analysis on high slope anchor lattice beam supporting structure[J]. Engineering Mechanics, 2015, 32(Suppl):271-276, 283. (in Chinese)
    [4] 江学良, 杨慧, 文畅平, 等. 地下采空区岩质边坡的施工过程数值分析[J]. 中国安全科学学报, 2013, 23(1):102-112. Jiang Xueliang, Yang Hui, Wen Changping, et al. Numerical analysis of construction process for rock slope with goaf[J]. China Safety Science Journal, 2013, 23(1):102-112. (in Chinese)
    [5] 刘晓玲. 采空区影响下的边坡稳定性分析[J]. 露天采矿技术, 2016, 21(1):32-35. Liu Xiaoling. Analysis of slope stability under the effect of goaf[J]. Opencast Mining Technology, 2016, 21(1):32-35. (in Chinese)
    [6] 唐春安, 唐烈先, 李连崇, 等. 岩土破裂过程分析RFPA离心加载法[J]. 岩土工程学报, 2007, 29(1):71-75. Tang Chun'an, Tang Liexian, Li Lianchong, et al. Centrifugal loading method of RFPA for the failure process analysis of rock and soil structure[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(1):71-75. (in Chinese)
    [7] Shi Genhua. Discontinuous deformation analysis a new numerical model for the static and dynamics of block system[M]. Berkeley, USA:Department of Civil Engineering, University of California, 1988:41-81.
    [8] 夏才初, 许崇帮. 非连续变形分析(DDA)中断续节理扩展的模拟方法研究和试验验证[J]. 岩石力学与工程学报, 2010, 29(10):2027-2032. Xia Caichu, Xu Chongbang. Study of fracturing algorithm of intermittent joint by DDA and experimental validation[J].Chinese Journal of Rock Mechanics and Engineering, 2010, 29(10):2027-2032. (in Chinese)
    [9] Tang Chun'an. Numerical simulation on progressive failure leading to collapse and as sociated seismicity[J]. International Journal of Rock Mechanics and Mining Science, 1997, 34(2):249-261
    [10] Tang Chun'an, Tang Shibin, Gong Bin, et al. Discontinuous deformation and displacement analysis:from continuous to discontinuous[J]. Science China TechnologicalSciences,2015, 58(9):1567-1574.
    [11] Gong Bin, Tang Chun'an. Slope-slide simulation with discontinuous deformation and displacement analysis[J]. International Journal of Geomechanics, 2017, 17(5):E4016017.
    [12] 朱万成, 唐春安, 杨天鸿, 等. 岩石破裂过程分析(RFPA2D)系统的细观单元本构关系及验证[J]. 岩石力学与工程学报, 2003, 23(1):1-30. Zhu Wancheng, Tang Chun'an, Yang Tianhong, et al. Constitutive relationship of mesoscopic elements used in RFPA 2D and its validations[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 23(1):1-30. (in Chinese)
    [13] 梁正召. 三维条件下的岩石破裂过程分析及其数值试验方法研究[D]. 沈阳:东北大学, 2005. Liang Zhengzhao. A dissertation in mining engineering three-dimensional failure process analysis of rock and associated numerical tests[D]. Shenyang:Northeastern University, 2005. (in Chinese)
    [14] 郑颖人. 岩土材料屈服与破坏及边(滑)坡稳定分析方法研讨——"三峡库区地质灾害专题研讨会"交流讨论综述[J]. 岩石力学与工程学报, 2007, 26(4):650-659. Zheng Yingren. Discussion on yield and failure of geomaterials and stability analysis methods of slope/landslide-Communion and discussion summary of special topic forum on geologic disasters in the three gorges project region[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(4):650-659. (in Chinese)
    [15] 吕海洋. 基于RFPA与DDA耦合的岩石破裂过程分析方法研究[D]. 大连:大连理工大学, 2014. Lü Haiyang. Rock failure process analysis based on RFPA combined DDA method[D]. Dalian:Dalian University of Technology, 2014. (in Chinese)
    [16] 陈力华, 靳晓光. 有限元强度折减法中边坡三种失效判据的适用性研究[J]. 土木工程学报, 2012, 45(9):137-145. Chen Lihua, Jin Xiaoguang. Study on the applicability of three criteria for slope instability using finite element strength reduction method[J]. China Civil Engineering Journal, 2012, 45(9):137-145. (in Chinese)
    [17] 邬爱清, 丁秀丽, 卢波, 等. DDA方法块体稳定性验证及其在岩质边坡稳定性分析中的应用[J]. 岩石力学与工程学报, 2008, 27(4):665-672. Wu Aiqing, Ding Xiuli, Lu Bo, et al. Validation for rock block stability and its application to rock slope stability evaluation using DDA method[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(4):665-672. (in Chinese)
