变轴力钢筋混凝土墩柱抗震性能研究

陈嵘; 雷俊卿

doi:10.6052/j.issn.1000-4750.2017.04.S046

变轴力钢筋混凝土墩柱抗震性能研究

陈嵘^1,2,
雷俊卿^1,

1.
北京交通大学土木建筑工程学院, 北京 100044;
2.
北京建筑大学北京高等学校工程研究中心, 北京 100044

基金项目: 国家自然科学基金项目（50878020，51178042，51478027）

详细信息

作者简介:
陈嵘(1976-),男,浙江人,讲师,博士生,主要桥梁抗震研究(E-mail:chenrong@bucea.edu.cn).

通讯作者:
雷俊卿(1957-),女,河南人,教授,博士,主要从事桥梁工程研究(E-mail:lei_jq@eyou.com).

中图分类号: U446.1
计量
- 文章访问数: 293
- HTML全文浏览量: 40
- PDF下载量: 46
出版历程
- 收稿日期: 2017-04-05
- 修回日期: 2017-10-30
- 刊出日期: 2018-06-29

Study on the seismic behavior of RC bridge piers under variable axial load

CHEN Rong^1,2,
LEI Jun-qing^1,

1.
School of Civil Engineering, Beijing Jiaotong University, Beijing 100044, China;
2.
Beijing Higher Institution Engineering Research Center of Civil Engineering Structure and Renewable Material, Beijing University of Civil Engineering and Architecture, Beijing 100044, China

摘要

摘要: 为研究墩柱在变轴力往复荷载下的抗震性能，制作6个试件，1个承受恒定轴力，5个承受变轴力，对比研究恒定轴力和变轴力，变轴力墩柱的不同纵筋配筋率、箍筋体积配箍率、高宽比对墩柱抗震性能的影响，试验表明轴力变化对位移、残余变形、破坏程度有较大影响。建立OpenSees纤维模型进行数值模拟，理论值与试验值符合较好。根据试验和理论分析总结规律，基于性能化设计方法给出建议。
- 钢筋混凝土桥墩 /
- 变轴力 /
- 抗震性能 /
- OpenSees /
- 性能化设计
Abstract: To study the seismic performance of RC bridge piers under variable axial force, six specimens are prepared, of which one was under constant axial load and the other five with different longitudinal reinforcement ratios, volumetric percentages of stirrups and shear span ratios, were subjected to variable axial force. The test results indicate that the variable axial force has apparent effect on the displacement, residual deformation, and the level of destruction of RC bridge piers. The fiber model was applied to simulate the piers under variable axial load and the theoretical results agree well with the experimental results. According to the performance-based seismic design, suggestions are proposed to consider varying axial load during design.
- reinforced concrete bridge pier /
- variable axial load /
- seismic performance /
- OpenSees /
- performance-based design

HTML全文

参考文献(17)

[1]	JTG B02-2013, 公路工程抗震设计规范[S]. 北京:人民交通出版社, 2013. JTG B02-2013, Specification of seismic design for highway engineering[S]. Beijing:China Communications Press, 2013. (in Chinese).
[2]	沈星, 叶爱群, 王晓伟. 双柱墩弹塑性位移能力简化计算方法[J]. 同济大学学报(自然科学版), 2014, 42(4):513-519. Shen Xing, Ye Aiqun, Wang Xiaowei. Simplified calculation method of elastic-plastic displacement capacity for double-column bent[J]. Journl of Tongji University (Natural Science), 2014, 42(4):513-519. (in Chinese)
[3]	邱法维, 钱稼茹, 陈志鹏. 结构抗震实验方法[M]. 北京:科学出版社, 2000:26-40. Qiu Fawei, Qian Jiaru, Chen Zhipeng. Experimental methods for earthquake resistant structure[M]. Beijing:Science Press, 2000:26-40. (in Chinese)
[4]	Kim T H, Kim Y J, Shin H M. Seismic performance assessment of reinforced concrete bridge columns under variable axial load[J]. Magazine of Concrete Research, 2007, 59(2):87-96.
[5]	Akguzel U, Pampanin S. Effects of variation of axial load and bidirectional loading on seismic performance of gfrp retrofitted reinforced concrete exterior beam-column joints[J]. Journal of Composites for Construction, 2010, 14(1):94-104.
[6]	Rodrigues H, Furtado A, Arêde A. Behavior of rectangular reinforced-concrete columns under biaxial cyclic loading and variable axial loads[J]. Journal of Structural Engineering, 2016, 142(1):1-8.
[7]	顾祥林, 蔡茂, 林峰. 地震作用下钢筋混凝土柱受力性能研究[J]. 工程力学, 2010, 27(11):160-165. Gu Xianglin, Cai Mao, Lin Feng. Study on RC columns subjected to earthquake[J]. Engineering Mechanics, 2010, 27(11):160-165. (in Chinese)
[8]	史庆轩, 王朋, 李坤, 等. 加载制度对新型型钢混凝土柱的抗震性能影响[J]. 工程力学, 2014, 31(3):152-159. Shi Qingxuan, Wang Peng, Li Kun, et al. Influence of loading regimes on seismic behavior of new type steel reinforced concrete columns[J]. Engineering Mechanics, 2014, 31(3):152-159. (in Chinese).
[9]	李海锋, 罗永峰, 陈林聪, 等. 轴力变化对箱形钢柱抗震性能的影响[J]. 西南交通大学学报, 2014, 49(3):425-431. Li Haifeng, Luo Yongfeng, Chen Lincong, et al. Effects of axial force fluctuation on seismic behavior of steel box column[J]. Journal of Southwest Jiaotong University, 2014, 49(3):425-431. (in Chinese)
[10]	王德斌, 范国玺, 张皓. 多维动力加载条件下钢筋混凝土柱力学性能的研究[J]. 振动与冲击, 2016, 35(4):35-41. Wang Debin, Fan Guoxi, Zhang Hao. Dynamic behavior of reinforced concrete columns under multi-dimensional dynamic loadings[J]. Journal of Vibration and Shock, 2016, 35(4):35-41. (in Chinese)
[11]	孙治国. 钢筋混凝土桥墩抗震变形能力研究[D]. 哈尔滨:中国地震局工程力学研究所, 2012. Sun Zhiguo. Research on the seismic deformation capacity of RC bridge columns[D]. Harbin:Institute of Engineering Mechanics, China Earthquake Administration, 2012. (in Chinese)
[12]	朱伯龙. 结构抗震试验[M]. 北京:地震出版社, 1989:136-141. Zhu Bolong. Aseismic test for structures[M]. Beijing:Seismological Press, 1989:136-141. (in Chinese)
[13]	JGJ/T 101-2015, 建筑抗震试验规程[S]. 北京:中国建筑工业出版社, 2015. JGJ/T 101- 2015, Specification for seismic test of buildings[S]. Beijing:China Architecture & Building Press, 2015. (in Chinese)
[14]	李贵乾, 郑罡, 王军. 圆形钢筋混凝土桥墩抗震性能(Ⅱ):试验结果评估[J]. 重庆交通大学学报(自然科学版), 2011, 30(6):1270-1274. Li Guiqian, Zheng Gang, Wang Jun. Seismic performance of circular reinforced concrete bridge columns (Ⅱ):evaluation of experimental results[J]. Journal of Chongqing Jiaotong University (Natural Science), 2011, 30(6):1270-1274. (in Chinese)
[15]	Hose Y, Seible F. Performance evaluation database for concrete bridge components and systems under simulated seismic loads[R]. California:Berkeley, 1999:12-15.
[16]	Mander J B, Priestley M J N, Park R. Theoretical stress-strain model for confined concrete[J]. Journal of Structural Engineering, 1988, 114(8):1804-1826.
[17]	JTG/T B02-01-2008, 公路桥梁抗震设计细则[S]. 北京:人民交通出版社, 2008. JTG/T B02-01-2008, Guidelines for seismic design of highway bridges[S]. Beijing:China Communications Press, 2008. (in Chinese)
