半开式桁架桥结构稳定性分析

岳子翔; 温庆杰; 卓涛

doi:10.6052/j.issn.1000-4750.2017.04.S052

半开式桁架桥结构稳定性分析

中国矿业大学力学与土木工程学院深部岩土力学与地下工程国家重点实验室, 江苏, 徐州 221116

基金项目: 中国工程建设标准化协会标准《铝合金人行天桥技术规程》编制项目（2013）；中国矿业大学青年科研基金项目（2012QNB28）；国家自然科学基金项目（51108452）

详细信息

作者简介:
岳子翔(1992-),男,江苏新沂人,硕士生,从事桥梁结构稳定性与可靠性研究(E-mail:827511232@qq.com);卓涛(1994-),男,江苏新沂人,硕士生,从事BIM在桥梁工程中应用的研究(E-mail:704107252@qq.com).

通讯作者:
温庆杰(1978-),男,河南西平人,副教授,博士,硕导,从事高强铝合金桥梁与结构设计理论研究(E-mail:cumtwenqingjie@126.com).

中图分类号: TU311.2
计量
- 文章访问数: 470
- HTML全文浏览量: 73
- PDF下载量: 49
出版历程
- 收稿日期: 2017-04-21
- 修回日期: 2017-12-12
- 刊出日期: 2018-06-29

Stability analysis of half-through truss bridge

School of Mechanics and Civil Engineering, State Key Laboratory for Geomechanics and Deep Underground Engineering, China University of Mining & Technology, Xuzhou, Jiangsu 221116, China

摘要

摘要: 半开式桁架桥无上部联系，其上弦杆易发生平面外屈曲。在上弦杆屈曲后的整桥体失稳模态中，存在明显的横向弯曲与扭转变形，上弦杆屈曲临界力和屈曲模态与理论结果有一定差异。该文使用有限元软件对一定数量的半开式桁架桥进行分析，通过有限元结果对影响桁架桥稳定性的因素进行了探讨，发现影响半开式桁架桥稳定性的尺寸参数是宽跨比，对这一桥型而言，稳定性与其宽跨比有正比关系；宽跨比对稳定性的影响来自其对整桥横向刚度和扭转刚度的影响，两种刚度共同决定整桥稳定性，但横向刚度是决定性因素；横向刚度会影响整桥失稳模态，若失稳模态产生突变，稳定性能随之产生巨大变化；对单座桥梁而言，若要通过增大宽跨比来提高稳定性，必须使两榀主桁建立有效联系，否则会起反作用；加装风撑能有效联系主桁，加强整桥横向刚度，进而提升整桥稳定性，但风撑无法加强抗扭刚度。
- 桥梁工程 /
- 半开式桁架桥 /
- 稳定性 /
- 横向刚度 /
- 扭转刚度 /
- 宽跨比 /
- 风撑
Abstract: Half-through truss bridges without upper lateral members are vulnerable to out-of-plane buckling of the upper chords. The instability modes caused by upper chords buckling involve obvious lateral bending and torsional deformation. The observed critical buckling load and buckling modes of upper chords are different with theoretical results. Based on FEA analysis, we analyzed some half-through truss bridges, and found that the stability is proportional to the width-span ratio. For those bridges, stability is directly proportional to its width-span ratio. The influence of the width span ratio on the stability was investigated by considering its influence on lateral stiffness and torsional stiffness. The influence of lateral stiffness is more significant, which affects the instability mode of the whole bridge. If the instability mode suddenly changes, the stability performance will change greatly. It is necessary to set effective link between the two main trusses of a bridge. Installing wind braces can effectively link the two main trusses, increase the lateral stiffness, and thus improve the stability, but the wind brace can not increase the torsional stiffness.
- bridge engineering /
- half-through truss bridge /
- stability /
- lateral stiffness /
- torsional stiffness /
- width-span ratio /
- wind braces

HTML全文

参考文献(12)

[1]	Timoshenko Gere. Theory of elastic stability[M]. 2nd ed. New York:McGraw- Hill, 1961:107-113.
[2]	小西一郎. 钢桥(第九分册)[M]. 北京:中国铁道出版社, 1981:87-90. Konishi Ichiro. Steel bridge (9th)[M]. Beijing:China Railway Press House, 1981:87-90. (in Chinese)
[3]	段明德, 黄耀怡. 对铁路《桥规》关于半穿式梁计算的建议[J]. 铁道标准设计通讯, 1984, 27(4):1-5. Duan Mingde, Huang Yaoyi. Suggestions on the calculation of the semi-dressed beam of railway bridge code[J]. Railway Standard Design, 1984, 27(4):1-5. (in Chinese)
[4]	张方银, 黄剑源. 半穿式桁架桥上弦杆侧向稳定性计算方法的研究[J]. 宁波大学学报(理工版), 1998, 11(2):62-68. Zhang Fangyin, Huang Jianyuan. Study of calculation method on lateral stability of top chord of half-through truss bridge[J]. Journal of Ningbo University (Natural Science & Engineering Edition), 1998, 11(2):62-68. (in Chinese)
[5]	JTS 152-2012, 水运工程钢结构设计规范[S]. 北京:人民交通出版社, 2012. JTS 152-2012, Code for design of steel structures in port and waterway engineering[S]. Beijing:China Communications Press, 2012. (in Chinese)
[6]	JTJ 283-99, 港口工程钢结构设计规范[S]. 北京:人民交通出版社, 2000. JTJ 283-99, Code for design of steel structure in port engineering[S]. Beijing:China Communications Press, 2000. (in Chinese)
[7]	TB 100091-2017, 铁路桥梁钢结构设计规范[S]. 北京:中国铁道出版社, 2017. TB 100091-2017, Code for design of steel structure of railway bridge[S]. Beijing:China Railway Publishing House, 2017. (in Chinese)
[8]	胡汉舟, 叶梅新. 桥梁事故及教训[J]. 桥梁建设, 2002, 32(3):71-75. Hu Hanzhou, Ye Meixin. Bridge accidents and lessons[J]. Bridge Construction, 2002, 32(3):71-75. (in Chinese)
[9]	宋宁, 尹越, 邓楠. 铝合金桁架步行桥设计及侧向稳定性分析[J]. 沈阳理工大学学报, 2011, 30(4):87-90. Song Ning, Yin Yue, Deng Nan. Design and lateral stability analysis of an aluminum alloy through truss footbridge[J]. Journal of Shenyang Ligong University, 2011, 30(4):87-90. (in Chinese)
[10]	张文元, 麦浩, 于海丰. 板式连接中心支撑钢框架结构推覆试验研究[J]. 工程力学, 2017, 34(10):128-138, 167. Zhang Wenyuan, Mai Hao, Yu Haifeng. Pushover tests of steel concentrically braced frameswith gusset plate connections[J]. Engineering Mechanics, 2017, 34(10):128-138, 167. (in Chinese)
[11]	Jankowska-Sandberg J, Kołodziej J. Experimental study of steel truss lateral-torsional buckling[J]. Engineering Structures, 2013, 46(46):165-172.
[12]	Biegus A. Trapezoidal sheet as a bracing preventing flat trusses from out-of-plane buckling[J]. Archives of Civil & Mechanical Engineering, 2015, 15(3):735-741.
