具有隔震构造的核电站安全壳在强烈地震和大型商用飞机撞击下的振动响应分析

李建波; 梅润雨; 于梦; 林皋

doi:10.6052/j.issn.1000-4750.2017.05.0335

具有隔震构造的核电站安全壳在强烈地震和大型商用飞机撞击下的振动响应分析

李建波^1,2,,
梅润雨^1,2,
于梦^1,2,
林皋^1,2

1.
海岸与近海工程国家重点实验室, 大连理工大学, 辽宁, 大连 116024;
2.
工程抗震研究所, 建设工程学部水利工程学院, 大连理工大学, 辽宁, 大连 116024

基金项目: 国家重点研发计划项目（2016YFB0201000）；国家自然科学基金项目（51779222）；国家自然科学基金委创新研究群体项目（51421064）；中央高校基本科研业务费项目（DUT17LK16）

详细信息

作者简介:
梅润雨(1991-),男,黄冈人,博士生,主要从事核电结构抗震分析和安全评价的研究(E-mail:meirunyu@mail.dlut.edu.cn);于梦(1993-),女,大连人,硕士生,主要从事核电结构抗震分析和安全评价的研究(E-mail:seven_5_27@mail.dlut.edu.cn);林皋(1929-),男,南昌人,教授,博士,院士,主要从事地震工程及结构抗震方面的研究(E-mail:gaolin@dlut.edu.cn).

通讯作者:
李建波(1977-),男,邢台人,副教授,博士,主要从事核电结构及水工结构抗震方面的研究(E-mail:jianboli@dlut.edu.cn).

中图分类号: TL364+.3
计量
- 文章访问数: 340
- HTML全文浏览量: 58
- PDF下载量: 69
出版历程
- 收稿日期: 2017-05-07
- 修回日期: 2017-11-07
- 刊出日期: 2018-09-28

VIBRATION RESPONSE ANALYSIS OF ISOLATED NUCLEAR CONTAINMENTS UNDER SEVERE EARTHQUAKE AND LARGE COMMERCIAL AIRCRAFT CRASH IMPACTS

LI Jian-bo^1,2,,
MEI Run-yu^1,2,
YU Meng^1,2,
LIN Gao^1,2

1.
State Key Laboratory of Coastal and Offshore Engineering, Dalian University of Technology, Dalian, Liaoning 116024, China;
2.
Institute of Earthquake Engineering, Faculty of Infrastructure Engineering, Dalian University of Technology, Dalian, Liaoning 116024, China

摘要

摘要: 核电站安全壳的安全性和完整性在建造运营期间必须要得到保证，尤其是对于强烈地震和飞机撞击等超设计基准事故。基础隔震作为一种能有效降低上部结构地震响应并防止结构破坏的典型隔震措施，在未来的核电站设计建造中备受关注，因而在核电站隔震系统的建造设计时应考虑大型商用飞机撞击的影响。该文基于CPR1000核电站安全壳，在底板下侧布置了不同型号的高阻尼橡胶隔震支座，从结构的隔震率（DAR）、最大水平位移和加速度反应谱，对安全壳在强烈地震作用下的隔振性能进行了综合分析。并结合采用荷载时程法以A320商用飞机撞击荷载为例进行飞机撞击核电站安全壳的分析，着重从飞机撞击后的振动衰减过程的振动特性以及飞机撞击诱导振动的加速度反应谱的分析结果对具有隔震构造的安全壳振动规律进行了分析。
- CPR1000安全壳 /
- 隔震支座 /
- 隔震分析 /
- 飞机撞击 /
- 振动规律
Abstract: The safety and integrity of nuclear power plant (NPP) containments must be guaranteed during the plant's lifecycle, especially in the event of severe earthquake and aircraft crashes. Base isolation, as a seismic isolation measure which can effectively reduce the seismic responses of the superstructure and prevent structural damage, draws much attention in the design and construction of nuclear power stations both at present and in the future. Therefore, it is necessary to consider the impacts of large commercial aircraft on the containment in the design of isolation systems for nuclear power plants. This paper studied and analyzed the isolation performance from decreasing amplitude ratio (DAR) and the maximum horizontal displacement of the containment on the basis of the CPR1000 containment with different types of high damping rubber bearing installed under the base mat. Moreover, it also conducted safety assessment of the containment with seismic isolation combined using the load time history method with taking the impact load of A320 commercial aircraft as an example. The primary results of the aircraft impact focused on the vibration characteristics of the vibration attenuation process and the acceleration response spectrum of the aircraft impact induced vibration processes.
- CPR1000 containment /
- isolation bearing /
- isolation analysis /
- aircraft impact /
- vibration law

HTML全文

参考文献(15)

[1]	Whittaker A S, Kumar M, Kumar M. Seismic isolation of nuclear power plants[J]. Nuclear Engineering & Technology, 2014, 46(5):569-580.
[2]	Huang Y N, Whittaker A S, Constantinou M C, et al. Seismic demands on secondary systems in base-isolated nuclear power plants[J]. Earthquake Engineering & Structural Dynamics, 2007, 36(12):1741-1761.
[3]	United States Nuclear Safety Management Committee. 10CFR50. 150:Aircraft Impact Assessment[EB/OL]. https://www.nrc.gov/reading-rm/doc-collections/cfr/part050/part050-0150.html,2009,8.
[4]	梅润雨, 李建波, 林皋. 具有隔震构造的安全壳飞机撞击耦合动力响应模拟分析[J]. 工程力学, 2017, 34(11):202-209. Mei runyu, Li Jianbo, Lin Gao. Dynamic response analysis of the isolated nuclear containment under coupling aircraft crash loads[J]. Engineering Mechanics, 2017, 34(11):202-209. (in Chinese)
[5]	IAEA, Safety aspects of nuclear power plants against human induced external events:margin assessment[R]. Draft Safety Report DD1086, 2014.
[6]	LS-DYNA Keyword User's Manual, Revision 971[M]. Liver More Software Technology Corportion, 2007.
[7]	赵春风. 强震及爆炸荷载作用下核岛厂房动力响应及减震抗爆措施研究[D]. 大连:大连理工大学, 2014. Zhao Chunfeng. Study on dynamic response and measures of seismic reduction and anti-explosion of nuclear island subjected to strong earthquakes and blast loads[D]. Dalian:Dalian University of Technology, 2014. (in Chinese)
[8]	Frano R L, Forasassi G. Isolation systems influence in the seismic loading propagation analysis applied to an innovative near term reactor[J]. Dalian:Nuclear Engineering & Design, 2010, 240(10):3539-3549.
[9]	Hua J, Mi G C. Aircraft impact analysis of nuclear safety-related concrete structures:A review[J]. Engineering Failure Analysis, 2014, 46:118-133.
[10]	Iqbal M A, Sadique M R, Bhargava P, et al. Damage assessment of nuclear containment against aircraft crash[J]. Nuclear Engineering and Design, 2014, 278(8):586-600.
[11]	Chen J, Zhao C, Xu Q, et al. Seismic analysis and evaluation of the base isolation system in AP1000 NI under SSE loading[J]. Nuclear Engineering & Design, 2014, 278:117-133.
[12]	曹健伟, 方秦, 龚自明, 等. 商用客机对核安全壳撞击破坏效应的数值模拟分析[J]. 工程力学, 2014, 31(9):63-70. Cao Jianwei, Fang Qin, Gong Ziming, et al. Numerical investigation on response and damage of nuclear containments under aircraft impact[J]. Engineering Mechanics, 2014, 31(9):63-70. (in Chinese)
[13]	Sang S S, Hahm D, Park T. Shock vibration and damage responses of primary auxiliary buildings from aircraft impact[J]. Nuclear Engineering & Design, 2016, 310:57-68.
[14]	Thai D K, Kim S E. Safety assessment of a nuclear power plant building subjected to an aircraft crash[J]. Nuclear Engineering & Design, 2015, 293:38-52.
[15]	NEI 07-13 Rev. 8, Methodology for performing aircraft impact assessments for new plant designs[S]. Washington:The Nuclear Energy Institute, USA, 2011.
