玻纤格栅配筋砌块墙体抗震性能试验研究

徐春一; 逯彪; 余希

doi:10.6052/j.issn.1000-4750.2017.06.S022

玻纤格栅配筋砌块墙体抗震性能试验研究

1.
沈阳建筑大学土木工程学院, 辽宁, 沈阳 110168;
2.
中建八局浙江建设有限公司, 浙江, 杭州 311215

基金项目: 国家自然科学基金项目（51408373）；辽宁省自然科学基金项目（20170540765）

详细信息

作者简介:
逯彪(1992-),男,黑龙江人,硕士生,从事现代砌体结构及加固改造研究(E-mail:250982776@qq.com);余希(1992-),男,浙江人,硕士,从事现代砌体结构及加固改造研究(E-mail:398853092@qq.com).

通讯作者:
徐春一(1983-),女,辽宁人,副教授,博士,硕导,从事现代砌体结构及加固改造研究(E-mail:xuchunyiyi@163.com).

中图分类号: TU352.11
计量
- 文章访问数: 435
- HTML全文浏览量: 67
- PDF下载量: 52
出版历程
- 收稿日期: 2017-06-01
- 修回日期: 2018-01-14
- 刊出日期: 2018-06-29

Experimental study on the seismic behavior of masonry wall with fiberglass geogrid

1.
School of Civil Engineering, Shenyang Jianzhu University, Shenyang, Liaoning 110168, China;
2.
Zhejiang Construction Co. Ltd of China Construction Eighth Engineer Division, Hangzhou, Zhejiang 311215, China

摘要

摘要: 针对配筋砌体存在配筋层砂浆灰缝较厚，不利于节能保温，该文采用玻纤格栅土工材料替代配筋砌体中的水平钢筋，可有效减小灰缝厚度、方便施工。为研究其抗震性能，该文采用四连杆机构加载装置分别对水平配玻纤格栅砌块墙体、水平配钢筋砌块墙体和无筋砌块墙体进行低周往复荷载试验，对比分析各类墙体的破坏特征及抗震性能。试验结果表明：水平配玻纤格栅可显著提高墙体抗剪承载力、变形能力及延性。其与无筋砌块墙体相比极限荷载提高了75%，极限位移提高了7.5倍，延性系数为无筋砌块墙体的3.61倍。其与配钢筋墙体相比各抗震性能指标较为接近，且略小于配钢筋墙体。采用玻纤格栅配置在砌体水平灰缝中，不仅可以实现薄灰缝砌体，提高砌体热工性能，还可显著提高砌体墙体的抗震性能，具有很好的应用前景，对砌体结构抗震及促进建筑节能具有重要的理论价值和现实意义。
- 玻纤格栅 /
- 配筋砌体 /
- 抗震性能 /
- 延性分析 /
- 蒸压加气混凝土
Abstract: The mortar seam in the reinforced masonry is thick, which is not conducive to energy saving and heat preservation. The glass fiber grille geotextile is used to replace the horizontal bar in the reinforced masonry. It can effectively reduce the thickness of mortar ash seam, leading to convenient construction. In order to study the seismic performance of horizontal glass fiber reinforced concrete block wall, horizontal reinforced concrete block wall and non-reinforced concrete block wall, the four-link-rod loading system is used to carry out cyclic test. The failure characteristics and seismic performance of various types of walls are compared and analyzed. Test results show that the horizontal glass fiber grille can significantly improve the shear capacity, deformation capacity and ductility of the wall. Compared with the non-reinforced concrete block wall, the ultimate load increases by 75%, the ultimate displacement increases by 7.5 times, and the ductility coefficient is 3.61 times of that without reinforcement. Compared with the reinforced concrete wall, the seismic performance index is slightly smaller than the reinforced concrete wall. The construction of fiber grille in masonry horizontal ash joints can not only improve thermal performance of the thin cracks in masonry, but also significantly improve the seismic performance of masonry walls. It has good application prospects, with important theoretical value and practical significance to promote the masonry structure seismic and building energy saving.
- glass fiber grill /
- reinforced masonry /
- seismic behavior /
- ductility analysis /
- autoclaved aerated concrete

HTML全文

参考文献(15)

[1]	王伟超, 李壮文. 建筑外墙保温节能技术研究进展[J]. 科技导报, 2013, 31(13):76-79. Wang Weichao, Li Zhuangwen. Progress on energy-saving technology on external wall[J]. Science &Technology Review, 2013, 31(13):76- 79. (in Chinese)
[2]	刘鑫. 无筋及水平灰缝配筋砌体干燥收缩试验研究[D]. 长沙:长沙理工大学, 2010. Liu Xin. Experimental research on drying shrinkage of unreinforced masonry and joint reinforced masonry[J]. Changsha:Changsha University of Science & Technology, 2010. (in Chinese)
[3]	邓明科, 樊鑫淼, 高晓军, 等. ECC面层加固受损砖砌体墙抗震性能试验研究[J]. 工程力学, 2015, 32(4):120-129. Deng Mingke, Fan Xinmiao, Gao Xiaojun, et al. Experimental investigation on seismic behavior of damaged brick masonry wall strengthened with ECC splint[J]. Engineering Mechanics, 2015, 32(4):120-129. (in Chinese)
[4]	白国良, 浮广明, 权宗刚, 等. 烧结保温空心砌块薄灰缝砌体基本力学性能试验研究[J]. 建筑结构学报, 2013, 34(10):151-158. Bai Guoliang, Fu Guangming, Quan Zonggang, et al. Experimental study on basic mechanical properties of fired heat-insulation hollow block thin mortar joint masonry[J]. Journal of Building Structures, 2013, 34(10):151-158. (in Chinese)
[5]	Ferrotti G, Canestrari F, Pasquini E, et al. Experimental evaluation of the influence of surface coating on fiberglass geogrid performance in asphalt pavements[J]. Geotextiles & Geomembranes, 2012, 34(10):11-18.
[6]	张斯, 徐礼华, 杨冬民, 等. 纤维布加固砖砌体墙平面内受力性能有限元模型[J]. 工程力学, 2015, 32(12):233-242. Zhang Si, Xu Lihua, Yang Dongmin, et al. Finite element modelling of FRP-reinforced masonry walls under modelling of FRP-reinforced masonry walls under in-plane loadings[J]. Engineering Mechanics, 2015, 32(12):233-242. (in Chinese)
[7]	Safavizadeh S A, Wargo A, Guddati M, et al. Investigating reflective cracking mechanisms in grid-reinforced asphalt specimens[J]. Transportation Research Record Journal of the Transportation Research Board, 2015, 25(7):29-38.
[8]	Yan C, Liu S, Deng Y. Experimental study on horizontal bearing capacity of cement-soil pile reinforced with fiberglass geogrid[J]. Geotechnical Special Publication, 2014, 23(5):88-97.
[9]	苑振芳, 刘斌, 苑磊. 砌体结构的耐久性[J]. 建筑结构, 2011, 25(4):117-121. Yuan Zhenfang, Liu Bin, Yuan Lei. Durability of masonry structures[J]. Building Structure, 2011, 25(4):117-121. (in Chinese)
[10]	张建伟, 杨兴民, 曹万林, 等. 带斜筋单排配筋低矮剪力墙的抗震性能[J]. 工程力学, 2016, 33(增刊1):125-132. Zhang Jianwei, Yang Xingmin, Cao Wanlin, et al. Seismic performance of low-rise shear wall with single layer of web reinforcement and inclined steel bars[J]. Engineering Mechanics, 2016, 33(Suppl 1):125-132. (in Chinese)
[11]	沈祥, 沙吾列提·拜开依, 阿力琴·阿布力提甫, 等. 网状CBF增强砖砌体轴心受力性能试验研究[J]. 工程力学, 2013, 30(增刊1):109-114. Shen Xiang, Sawule Bekey, Aliqin Abulitipu, et al. Experiment research on CBF mesh reinforced brick masonry under axial compressive loading[J]. Engineering Mechanics, 2013, 30(Suppl 1):109-114. (in Chinese)
[12]	吴敏莉. 夏热冬冷地区居住建筑墙体保温节能特性研究[D]. 杭州:浙江大学, 2014. Wu Minli. Energy saving effect of wall insulation of residential buildings in hot summer and cold winter climate zones[D]. Hangzhou:Zhejiang University, 2014. (in Chinese)
[13]	GB 50003-2011, 砌体结构设计规范[S]. 北京:中国建筑工业出版社, 2011. GB 5003-2011, Code for design of masonry structures[S]. Beijing:China Architecture Industry Press, 2011. (in Chinese)
[14]	赵成文, 张亮, 高连玉, 等. A类蒸压加气混凝土砌块墙体抗震性能试验[J]. 沈阳建筑大学学报, 2009, 25(3):426-432. Zhao Chenwen, Zhang Liang, Gao Lianyu, et al. Experimental study on seismic performance of autoclaved aerated concrete block bearing walls[J]. Journal of Shenyang Jianzhu University, 2009, 25(3):426-432. (in Chinese)
[15]	苏启旺, 赵世春, 叶列平. 砌体结构抗震评估研究[J]. 建筑结构学报, 2014, 35(1):111-116. Su Qiwang, Zhao Shichun, Ye Lieping. Research on seismic evaluation of masonry structures[J]. Journal of Building Structures, 2014, 35(1):111-116. (in Chinese)
