HYDRAULIC PERFORMANCES IN MAINSTREAM OF DRIP IRRIGATION PIPE
-
摘要: 以质量和动量守恒定理为依据，建立了以内镶式滴灌管为例的多孔管流动数学模型，并结合水力试验数据，推导得出了内镶式滴灌管内部主流道的沿程压力分布模型。多孔管流动的数学模型表明：多孔管主流道内的压力大小及变化取决于摩阻作用和动量交换作用的相对大小，其中摩阻作用使得压力降低，动量交换作用使压力升高，多孔管压力分布模型可以归结为求解管路摩阻系数和动量交换系数。滴灌管水力试验表明：滴灌管沿程纵向流速的分布指数与滴头自身特性（流量系数、流态指数）无关，而与管路上的滴头个数呈良好的线性相关关系。以水力试验数据分析与理论推导为基础，得出动量交换系所对应的经验表达式，结合BLASIUS摩阻系数计算公式对滴灌管压力分布模型进行求解，模型预测值与实测值吻合良好。该压力分布模型中，将沿程压力分布的影响因素归结为滴灌管长径比和管首雷诺数，便于优化结构设计及确定最佳运行工况。该文可为多孔管路水力计算及变质量流动模型研究提供一定参考。Abstract: Based on the theorem of mass and momentum conservation, this study established an analytical model for variable mass flow, and thusly developed a mathematical expression for the longitudinal pressure distribution along the mainstream of a drip irrigation pipe combined with experimental data. The established model shows that the longitudinal pressure distribution in the drip irrigation pipe is dependent on friction head loss and momentum exchange, and that friction head loss tends to decrease the pressure and the momentum exchange tends to increase it. The solution of the longitudinal pressure distribution model is attributed to determining friction and momentum exchange coefficients. The test results show that distribution index of longitudinal velocity is independent of the characteristic parameters of the drip irrigation pipe, but linear with the number of drip emitters. The expression for the momentum exchange coefficient was obtained by theoretical derivation and regression analysis, and the friction coefficient can be calculated by Blasius formula. The analytical model for variable mass flow and the longitudinal pressure expression for the drip irrigation pipe was then solved. The calculated values of the longitudinal pressure along the drip irrigation pipe agreed well with measured values. In the longitudinal pressure expression, pressure is affected by a pipe-structure parameter (length-diameter ratio)and a flow parameter (entrance Reynolds number). The expression helps guide the structural design and optimize operating conditions, because the two parameters are both directly controllable. This study offers a new thought for the analysis of variable mass flow, and the results would provide a scientific basis for the hydraulic calculation of drip irrigation.
-
-
[1] Baiamonte G. Advances in designing drip irrigation laterals[J]. Agricultural Water Management, 2018, 199:157-174. [2] Reinders F B, Niekerk A S V. Technology smart approach to keep drip irrigation systems functional[J]. Irrigation & Drainage, 2018, 67(1):82-88. [3] Stoochnoff J A, Graham T, Dixon M A. Drip irrigation scheduling for container grown trees based on plant water status[J]. Irrigation Science, 2018, 36(2):1-8. [4] Francisco Alcon, María Dolores de-Miguel, Michael Burton. Duration analysis of adoption of drip irrigation technology in southeastern spain[J]. Technological Forecasting and Social Change, 2011, 78(6):991-1001. [5] 张国祥, 吴普特. 滴灌系统滴头设计水头的取值依据[J]. 农业工程学报, 2005, 21(9):20-22. Zhang Guoxiang, Wu Pute. Determination of the design working head of emitter[J]. Transactions of the Chinese Society of Agricultural Engineering(Transactions of the CSAE), 2005, 21(9):20-22. (in Chinese) [6] Wu I P, Gitlin H M. Design of irrigation lines[J]. Technical Bulletin of the University of Hawaii, 1974a, 96(1):3-29. [7] Wu I P, Gitlin H M. Drip irrigation design based on uniformity[J]. Transactions of the ASAE, 1974b, 17(3):429-432. [8] Wu I P. A uni-plot for drip irrigation lateral and submain design[J]. Transactions of the ASAE, 1985, 28(2):522-528. [9] Jain S K, Singh K K, Singh R P, et al. Micro-irrigation lateral design using lateral discharge equation[J]. Journal of Irrigation and Drainage Engineering, 2002, 128(2):125-128. [10] Kang Y. H., Nishiyam A. S. Design of micro-irrigation sub-main units[J]. ASCE. Journal of Irrigation and Drainage Engineering, 1996, 122(2):83-89. [11] Kang Y H, Nishiyama S. Hydraulic analysis of microirrigation submain nuits[J]. Transactions of the ASAE, 1995, 38(5):1377-1384. [12] Kang Y H, Nishiyama S. A simplified method for design of microirrigation laterals[J]. Transactions of the ASAE, 1996d, 39(5):1681-1687. [13] Demir V, Yurdem H, Degirmencioglu A, et al. Development of prediction models for friction losses in drip irrigation laterals equipped with integrated in-line and on-line emitters using dimensional analysis[J]. Bio-systems Engineering, 2007, 96(4):617-631. [14] Wang Y, Zhu D, Lin Z. Dimensional analysis for estimating the local head losses in trickle laterals equipped with integrated in-line emitters[J]. Journal of Hydraulic Engineering, 2015, 46(5):602-611. [15] Gomes A W A, Frizzone J A, Rettore Neto O, et al. Local head losses for integrated drippers in polyethylene pipes[J]. Engenharia Agrícola, 2010, 30(3):435-446. [16] Zitterell D B, Frizzone J A, Neto O R. Dimensional analysis approach to estimate local head losses in microirrigation connectors[J]. Irrigation Science, 2014, 32(3):169-179. [17] Zitterell D B, Frizzone J A, Neto O R. Dimensional analysis approach to estimate local head losses in microirrigation connectors[J]. Irrigation Science, 2014, 32(3):169-179. [18] Sadeghi S H, Peters R T, Lamm F R. Design of Zero Slope Microirrigation Laterals:Effect of the Friction Factor Variation[J]. Journal of Irrigation & Drainage Engineering, 2015, 141(10):04015012. [19] 王新坤. 基于二分法的微灌毛管水力设计[J]. 排灌机械工程学报, 2007, 25(6):27-30. Wang Xinkun. Hydraulic design of micro-irrigation laterals based on bisection method[J]. Drainage and Irrigation Machinery, 2007, 25(6):27-30. (in Chinese) [20] 白丹, 王新. 基于遗传算法的多孔变径管优化设计[J]. 农业工程学报, 2005, 21(2):42-45. Bai Dan, Wang Xin. Optimum design for tapered diameter pipeline with multiple outlets based on genetic algorithm[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2005, 21(2):42-45. (in Chinese) [21] Martí P, Provenzano G, Royuela Á, et al. Integrated emitter local loss prediction using artificial neural networks[J]. Journal of Irrigation & Drainage Engineering, 2010, 136(1):11-22. [22] Provenzano G, Dio P D, Salvador G P. New computational fluid dynamic procedure to estimate friction and local losses in coextruded drip laterals[J]. Journal of Irrigation and Drainage Engineering, 2007, 133(6):520-527. [23] 王福军, 王文娥. 滴头流道CFD分析的研究进展与问题[J]. 农业工程学报, 2006, 22(7):188-192. Wang Fujun, Wang Wen'e. Research progress in analysis of flow passage in irrigation emitters using computational fluid dynamics techniques[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2006, 22(7):188-192. (in Chinese) [24] 王新坤, 许文博, 赵坤,等. 基于CFD的多孔管热风数值模拟与设计方法[J]. 排灌机械工程学报, 2011, 29(1):82-86. Wang Xinkun, Xu Wenbo, Zhao Kun, et al. Numerical simulation and design method of hot air for porous pipe based on CFD[J]. Drainage and Irrigation Machinery, 2011, 29(1):82-86. (in Chinese) [25] 丁法龙, 茅泽育, 王文娥,等. 滴灌管主流道沿程压力分布模型及验证[J]. 农业工程学报, 2019, 35(3):117-124. Ding Falong, Mao Zeyu, Wang Wen'e, et.al. Modelling and verification of pressure distribution along mainstream in drip irrigation pipe[J]. Transactions of the Chinese Society of Agricultural Engineering, 2019, 35(3):117-124. (in Chinese) [26] McNown J S. Mechanics of manifold flow[J]. Transactions of the American Society of Civil Engineers, 1954, 119(7):1103-1118. [27] 杜涛, 刘焕芳, 金瑾. 沿程出流多孔流体分布管压力分布特性[J]. 化学工程, 2014, 42(9):48-52. Du Tao, Liu Huanfang, Jin Jin. Pressure distribution characteristics of perforated pipe outflow along pipeline[J]. Chemical Engineering (China), 2014, 42(9):48-52. (in Chinese) [28] Bagarello V, Ferro V, Provenzano G, et al. Evaluating pressure losses in drip-irrigation lines[J]. Journal of Irrigation & Drainage Engineering, 1997, 123(1):1-7. [29] Pumo D, Provenzano G. Experimental Analysis of Local Pressure Losses for Microirrigation Laterals[J]. Journal of Irrigation & Drainage Engineering, 2004, 130(4):318-324. -
