RESPONSE ANALYSIS OF TRANSMISSION TOWER-LINE SYSTEM UNDER SMART-1 SEISMIC GROUND MOTION EXCITATION
-
摘要: 该文研究了SMART-1台阵多维多点地震激励下输电塔-线体系的反应。根据输电线路实际工程，在考虑输电线的几何非线性基础上，建立了输电塔-线耦联体系的三维有限元计算模型。选取了SMART-1台阵中不同方向上的多维多点地震动时程，分别研究了不同折线角度下输电塔线体系多维一致和多维多点地震反应。研究结果表明：不同夹角下输电塔-线体系在多维多点激励下的反应均大于多维一致激励下的反应，但随着角度不同，增大程度也不同，尤其是输电线的竖向位移得到了强烈的放大。通过实际的多维多点地震动研究了输电线路不同角度下的反应，对应角度不同，输电线路受地震动多维多点效应影响不同。所获得的分析结果可为输电线路抗震设计提供 参考。Abstract: The responses of a transmission tower-line system under multi-component multi-support excitations of SMART-1 seismic array are investigated. A three-dimensional finite element model of a transmission tower-line coupled system considering the geometric nonlinearity of a transmission line is established based on a practical engineering project. The multi-component multi-support seismic time history of SMART-1 seismic array is selected, and the responses of a transmission tower-line system with different unfold type angles under multi-component uniform and multi-component multi-support excitations are studied, respectively. The results show that the responses of a transmission tower-line system under multi-component multi-support excitations are larger than those under multi-component uniform excitations, but the increasing degrees vary with the change of angles, especially the vertical displacement of a transmission line is strongly amplified. The response of a transmission line is studied with different angles according to real multi-component multi-support seismic waves, and the multi-component multi-support earthquakes have different influences on a transmission line with different angles. The analysis results obtained could provide a reference for the aseismic design of transmission lines.
-
-
[1] 李宏男),(王前信). 大跨越输电塔体系的动力特性[J]. (土木工程学报), 1997,30(5):28―36. Li Hongnan, Wang Qianxin. Dynamic characteristics of long-span transmission lines and their supporting towers [J]. China Civil Engineering Journal,1997,30(5): 28―36. (in Chinese [2] 谢强),(李杰). 电力系统自然灾害的现状与对策[J]. (自然灾害学报), 2006,15(4):126―131. Xie Qiang, Li Jie. Current situation of natural disaster in electric power system and countermeasures [J]. Journal of Natural Disasters,2006,15(4): 126―131. (in Chinese [3] 尹荣华),(李东亮),(刘戈林),(翟桐). 高压输电塔震害及抗震研究[J]. (世界地震工程), 2005,21(1):51―54. Yin Ronghua, Li Dongliang, Liu Gelin, Zhai Tong. Seismic damage and analysis of power transmission towers [J]. World Earthquake Engineering,2005,21(1): 51―54. (in Chinese [4] 李宏男) 结构多维抗震理论[M]. 北京: 科学出版社, 2006: 417―434. Li Hongnan. Theoretical analysis of structures to multiple earthquake excitations [M]. Beijing: Science Press, 2006: 417―434. (in Chinese [5] 杨庆山),(刘文华),(田玉基). 国家体育场在多点激励作用下的地震反应分析[J]. (土木工程学报), 2008,41(2):35―41. Yang Qingshan, Liu Wenhua, Tian Yuji. Response analysis of national stadium under specially variable earthquake ground motions [J]. China Civil Engineering Journal,2008,41(2): 35―41. in Chinese
