核环吊平衡路径与吊重轨迹偏差

齐朝晖; 宋慧涛; 张志刚

doi:10.6052/j.issn.1000-4750.2012.09.0673

核环吊平衡路径与吊重轨迹偏差

工业装备与结构分析国家重点实验室,大连理工大学工程力学系,辽宁,大连 116024

基金项目: 国家自然科学基金项目(10972044)

详细信息

作者简介:
宋慧涛(1985―)，男，菏泽人，博士生，从事多体系统动力学研究(E-mail: sht_214@163.com)；张志刚(1984―)，男，开封人，博士生，从事多体系统动力学研究(E-mail: zhigangzhang@foxmail.com).

通讯作者:
齐朝晖(1964―),男,大连人,教授,博士,博导,从事多体系统动力学研究(E-mail: zhaohuiq@dlut.edu.cn).

中图分类号: TH11
计量
- 文章访问数: 246
- HTML全文浏览量: 18
- PDF下载量: 79
出版历程
- 收稿日期: 2012-09-15
- 刊出日期: 2014-01-24

EQUILIBRIUM PATHS AND LOAD TRAJECTORY DEFLECTIONS OF NUCLEAR RING CRANES

State Key Laboratory of Structural Analysis for Industrial Equipment, Department of Engineering Mechanics, Dalian University of Technology, Dalian, Liaoning 116024, China

摘要

摘要: 提出了一种分析核环吊系统吊重轨迹偏差的系统化方法——平衡路径法,给出了平衡路径方程和协调条件,并详细讨论了方程中所涉及的各种变量的性质和计算方法；考虑了动滑轮位置改变所引起的钢丝绳拉力方向的变化,提出了确保与钢丝绳绕绳方式一致的空间滑轮公切线求解方法；给出了卷筒卷入绳长、钢丝绳分支中绳长的计算方法,以及滑轮两端绳速传递关系。这些问题的解决方法具有一定的普适性,可应用于一般滑轮绳索系统。
- 核环吊 /
- 绳索滑轮系统 /
- 平衡路径 /
- 轨迹偏差 /
- 滑轮公切线
Abstract: A systematic method for analyzing load trajectory deflections of nuclear ring cranes was presented, including the governing equations of equilibrium paths and their compatibility conditions. Properties and formulations of the variables involved in these equations were studied in detail, in which the variation in pull directions of ropes with positions of pulleys was taken into account and a numerical method was derived to ensure the roping manner conforming to the common tangent of two pulleys. Moreover, we also provided a method to compute rope lengths wound by the drum and between two out rope points on pulleys, and the transitive relation for rope velocities between two ends of the pulley was derived. To a large extent the proposed method is universal and can be applied to general rope-pulley systems.
- nuclear ring cranes /
- rope-pulley systems /
- equilibrium paths /
- trajectory deflections /
- common tangent of pulleys

HTML全文

参考文献(21)

[1]	李波. 核电站环吊大车运行动力学研究[D]. 上海: 上海交通大学, 2007.
[2]	Li Bo. Study on polar crane dynamics of nuclear power plant [D]. Shanghai: Shanghai Jiaotong University, 2007. (in Chinese)
[3]	[2]顾翠云, 高秀芬, 刘焕江, 等. 核电站环行起重机安全保护功能分析[J]. 机械工程与自动化, 2009(6): 93―94.
[4]	Gu Cuiyun, Gao Xiufen, Liu Huanjiang, et al. Safety and protection function analysis of polar crane in nuclear power station [J]. Mechanical Engineering & Automation, 2009(6): 93―94. (in Chinese)
[5]	[3]李国杰, 丁晓红. 日本核电站桥式起重机[J]. 起重运输机械, 2001(2): 20―24.
[6]	Li Guojie, Ding Xiaohong. Overhead travelling crane for nuclear power station in Japan [J]. Hoisting and Conveying Machinery, 2001(2): 20―24. (in Chinese)
[7]	[4]卜广强. 核电站起重机面临的问题及其对策[J]. 起重运输机械, 2010(4): 5―10.
[8]	Bu Guangqiang. Issues confronted with cranes for nuclear power plants and its related countermeasures [J]. Hoisting and Conveying Machinery, 2010(4): 5―10. (in Chinese)
[9]	[5]胡宗武, 阎以诵. 起重机动力学[M]. 北京: 机械工业出版社, 1988: 1―11.
[10]	Hu Zongwu, Yan Yisong. Crane Dynamics [M]. Beijing: China Machine Press, 1988: 1―11. (in Chinese)
[11]	[6]王鹏程, 方勇纯, 相吉磊, 等. 回转旋臂式船用起重机的动力学分析与建模[J]. 机械工程学报, 2011, 47(20): 34―40.
[12]	Wang Pengcheng, Fang Yongchun, Xiang Jilei, et al. Dynamics analysis and modeling of ship-mounted boom crane [J]. Journal of Mechanical Engineering, 2011, 47(20): 34―40. (in Chinese)
[13]	[7]郭永娟. 起重机吊重偏摆系统的动力学仿真与控制研究[D]. 哈尔滨: 东北林业大学, 2011.
[14]	Guo Yongjuan. Research on dynamic simulation and control of load deflection systems for cranes [D]. Harbin: Northeast Forestry University, 2011. (in Chinese)
[15]	[8]Aufaure M. A finite element of cable passing through a pulley [J]. Computers and Structures, 1993, 46(5): 807―812.
[16]	[9]Ju F, Choo Y S. Super element approach to cable passing through multiple pulleys [J]. International Journal of Solids and Structures, 2005(42): 3533―3547.
[17]	[10]Hong D W, Cipra R J. A method for representing the configuration and analyzing the motion of complex cable-pulley systems [J]. Journal of Mechanical Design, 2003, 125: 332―341.
[18]	[11]齐朝晖. 多体系统动力学[M]. 北京: 科学出版社, 2008: 145―148.
[19]	Qi Zhaohui. Dynamics of multibody systems [M]. Beijing: Science Press, 2008: 145―148. (in Chinese)
[20]	[12]张青, 张瑞军. 工程起重机结构与设计[M]. 北京: 化学工业出版社, 2008: 37―39.
[21]	Zhang Qing, Zhang Ruijun. Structure and design of engineering crane [M]. Beijing: China Industry Press, 2008: 37―39. (in Chinese)
