EXPERIMENTAL STUDY ON POST-ELEVATED TEMPERATURE MECHANICAL PROPERTIES OF BUTT-WELDED CONNECTIONS
-
摘要: 对39个对接焊缝连接接头试件进行了高温冷却后的拉伸试验,研究了高温过火对其强度和变形性能的影响规律。试验的主要参数为过火温度和冷却方式,其中过火温度介于200℃~800℃,冷却方式包括自然冷却和泼水冷却。试验结果表明,常温下发生母材塑性破坏的对接焊缝试件,在过火温度较高时全部发生焊缝断裂,试样无明显颈缩,破坏突然;过火温度超过400℃后,冷却方式对对接焊缝连接试件的高温后力学性能有较大影响,自然冷却情况下试件从500℃开始发生焊缝断裂,试件极限强度和极限变形最大降低幅度分别为20%和50%,泼水冷却情况下试件从600℃开始发生焊缝断裂,试件极限强度和极限变形最大降低幅度分别为10%和35%。Abstract: Post-elevated temperature mechanical properties of butt-welded connections were investigated in this study. 39 specimens were heated to different maximum temperature from 200 to 800℃ and held for 60 minutes. They were subsequently cooled to ambient temperature naturally or by water, and finally stretched to failure. Results show that for butt-welded connections that fail in basic metal at room temperature, fracture failure happens, and the failure position changes to the butt weld when the exposed temperature is high. Cooling methods have a great effect on mechanical properties of butt-welded connections after fire when the exposed temperature is above 400℃. For natural cooling, specimens begin to fail in butt weld at a temperature of 500℃, and the maximum decreases in the ultimate strength and the corresponding deformation are 20% and 50%, respectively. For water cooling, specimens begin to fail in butt weld from 600℃, and the maximum decreases in the ultimate strength and deformation are about 10% and 35%, respectively.
-
-
[1] 蒋首超, 李国强, 韩兵康, 彭航. 某钢结构梯架火灾后性能分析与鉴定[J]. 结构工程师, 2009, 25(1): 124―127.
Jiang Shouchao, Li Guoqiang, Han Bingkang, Peng Hang. Appraisal on structural safety of a steel frame after fire [J]. Structural Engineers, 2009, 25(1): 124―127. (in Chinese)[2] 王卫永, 董毓利, 隋炳强. 焊接钢框架边节点抗火性能试验[J]. 东南大学学报(自然科学版), 2007, 37(2): 240―244.
Wang Weiyong, Dong Yuli, Sui Bingqiang. Fire-resistant experiment of welded single-sided joint of steel frame [J]. Journal of Southeast University (Natural Science Edition) , 2007, 37(2): 240―244. (in Chinese)[3] 余红霞, 刘涛. 美国世贸中WTC7次梁-柱节点高温下的破坏行为分析[J]. 钢结构, 2010, 8(25): 76―82.
Yu Hongxia, Liu Tao. Analysis of behavior of secondary beam-column connections of WTC7 at high temperature [J]. Steel Structure, 2010, 8(25): 76―82. (in Chinese)[4] Yu L. Behavior of bolted connections during and after a fire [D]. Austin: University of Texas at Austin, 2006. [5] 楼国彪, 俞珊, 王锐. 高强度螺栓过火冷却后力学性能试验研究[J]. 建筑结构学报, 2012, 33(2): 33―40.
Lou Guobiao, Yu Shan, Wang Rui. Mechanical properties of high-strength bolts after fire [J]. Journal of Building Structures, 2012, 33(2): 33―40. (in Chinese)[6] Lou Guobiao, Zhu Meichun, Li Ming, Zhang Chao, Li Guoqiang. Experimental research on slip-resistant bolted connections after fire [J]. Journal of Constructional Steel Research, 2015,104(1): 1―8. [7] Hanus F, Zilli G, Franssen J M. Experimental tests and analytical models for welds and Grade 8.8 bolts under heating and subsequent cooling [J] Journal of Structural Fire Engineering, 2011, 2(3): 181―194. [8] 陈建锋, 曹平周, 董先锋. 高温后正面角焊缝抗拉剪切强度的试验[J]. 焊接学报, 2009, 30(9): 81―84.
Chen Jianfeng, Cao Zhouping, Dong Xianfeng. Experiment on tensile-shear strength of post-elevated temperature transverse fillet weld [J]. Transactions of the China Welding Institution, 2009, 30(9): 81―84. (in Chinese)[9] GB/T 2651-2008, 《焊接接头拉伸试验方法》[S]. 北京: 中国标准出版社, 2008.
GB/T 2651-2008, Tensile test method on welded joints [S]. Beijing: China Standards Press, 2008. (in Chinese)[10] GB 50017-2003, 《钢结构设计规范》[S]. 北京: 中国计划出版社, 2003.
GB 50017-2003, Code for design of steel structure [S]. Beijing: China Planning Press, 2003. (in Chinese) -
