Experimental study on exterior joint of damage control steel frame
-
摘要: 该文提出一种损伤可控型钢框架节点（DCSF节点）。在梁端腹板上设置连接钢板，通过高强摩擦螺栓将梁、柱拼接在一起，并在梁内布置预应力筋来提供节点的复位能力。在小震作用下，通过高强螺栓来提供节点的初始刚度和抗弯承载力；在中震作用下，通过螺栓杆在螺栓孔壁内的滑移来改善节点的耗能，以此避免梁、柱主体构件受到损伤。共设计完成了4个足尺试件的低周往复加载试验，分别考虑了连接钢板的不同接触表面、预应力筋的初张拉值以及高强螺栓预紧力对该类节点的初始刚度、损伤特征、滞回性能和自复位能力的影响。研究结果表明：高强螺栓在螺栓孔内的滑移为节点提供了良好的耗能能力；预应力筋能够减少结构的残余变形，提供节点的自复位能力；当层间位移角达2.4%时，主体构件未发现明显损伤，螺栓杆与孔壁发生挤压破坏，更换连接钢板后，节点的承载力和耗能能力基本不变，DCSF节点具有良好的抗震性能；节点的连接无需现场施焊，施工方便、快捷，可在地震区推广应用。Abstract: This paper presents a damage control steel-frame-joint (DCSF joint). By setting a splice plate on the web of a beam end, a beam and a column are connected by high strength friction bolts, and the prestressed reinforcement in the beam can provide re-centering capacity for the joint. Under a small earthquake, high strength friction bolts provide the initial stiffness and flexural bearing capacity for the joint; under a medium earthquake, and the slip of a bolt rod in a bolt hole dissipates energy for the joint. Therefore, main structural members are protected from damage. In order to study the initial stiffness, damage characteristics, hysteretic behavior and re-centering capacity of the joint, four full-size specimens were designed and tested under cyclic loading. Considering the effects of different contact surfaces of splice plates, the pretension of prestressed reinforcement, and pre-tightening force of high strength bolts respectively, the experimental study shows that:the slip of a high strength bolt rod in a bolt hole can provide good energy dissipation ability for the joint; the prestressed reinforcement can reduce the residual deformation of the structure and provide re-centering capacity for the joint; when inter-story displacement angle reaches 2.4%, the damage was mainly concentrated in bolt rods and the extrusion area of bolt holes on a splice plate, no obvious damage was found in main structural members. The bearing capacity and energy dissipation capacity of the joint basically remains unchanged after replacing the splice plate. The results of the study show that DCSF joint can be popularized and applied in earthquake regions due to its good seismic performance and convenient construction process without site welding.
-
-
[1] 薛伟辰. 预制混凝土框架结构体系研究与应用进展[J]. 工业建筑, 2002, 32(11):47-50. Xue Weichen. Progress of studies and applications of precast concrete frame structure systems[J]. Industrial Construction, 2002, 32(11):47-50. (in Chinese) [2] 邹昀, 林晖, 马卫强. 具有自复位功能装配式框架节点抗震性能的影响因素分析[J]. 工程力学, 2015, 32(增刊2):72-77. Zou Yun, Lin Hui, Ma Weiqiang. Influence factors analysis on aseismic behavior of prefabricated frame joints with capacity of self-centering[J]. Engineering Mechanics, 2015, 32(Suppl 2):72-77. (in Chinese) [3] 李波, 杨庆山, 茹继平, 等. 梁腹板开圆孔的钢框架抗震性能研究[J]. 工程力学, 2009, 26(1):64-73. Li Bo, Yang Qingshan, Ru Jiping, et al. Investigation on aseismic behaviors of steel moment resisting frame including opening in beam web[J]. Engineering Mechanics, 2009, 26(1):64-73. (in Chinese) [4] 李启才, 刘刚, 胡安吉, 等. 钢框架中钢梁高强螺栓拼接摩擦耗能的试验研究[J]. 建筑结构, 2011, 41(5):78-81. Li Qicai, Liu Gang, Hu Anji, et al. Experimental study on frictional energy-dissipation behavior of bolted steel beam splicing in rigid frame[J]. Building Structure, 2011, 41(5):78-81. (in Chinese) [5] 郁有升, 王燕. 钢框架梁翼缘削弱型节点力学性能的试验研究[J]. 工程力学, 2009, 26(2):168-175. Yu Yousheng, Wang Yan. Experimental study on the mechanical property of reduced beam section connections of steel frames[J]. Engineering Mechanics, 2009, 26(2):168-175. (in Chinese) [6] Kim H J, Christopoulos C. Friction damped post tensioned self-centering steel moment-resisting frames[J]. Journal of Structural Engineering, 2008, 134(11):1768-1779. [7] 蔡小宁, 孟少平, 孙巍巍. 自复位预制框架边节点组件受力性能试验研究[J]. 工程力学, 2014, 31(3):160-167. Cai Xiaoning, Meng Shaoping, Sun Weiwei. Experimental study on performance of components of the exteriors self-centering post-tensioned precast connections[J]. Engineering Mechanics, 2014, 31(3):160-167. (in Chinese) [8] 蔡小宁, 孟少平. 预应力自复位混凝土框架节点抗震性能数值模拟[J]. 工程力学, 2016, 33(3):143-151. Cai Xiaoning, Meng Shaooing. Numerical analysis for seismic behavior of self-centering post-tensioned precast beam-to-column connections[J]. Engineering Mechanics, 2016, 33(3):143-151. (in Chinese) [9] 蔡小宁, 孟少平. 预应力自复位混凝土框架节点恢复力模型研究[J]. 工程力学, 2018, 35(1):182-200. Cai Xiaoning, Meng Shaooing. Research on restoring force model of the prestressed self-centering concrete frame joints[J]. Engineering Mechanics, 2018, 35(1):182-200. (in Chinese) [10] 周颖, 吕西林. 摇摆结构及自复位结构研究综述[J]. 建筑结构学报, 2011, 32(9):1-10. Zhou Ying, Lü Xilin. State-of-the-art on rocking and self-centering structures[J]. Journal of Building Structures, 2011, 32(9):1-10. (in Chinese) [11] 纪晓东, 马琦峰, 王彦栋, 等. 连梁可更换消能梁段抗震性能试验研究[J]. 建筑结构学报, 2014, 35(6):1-11. Ji Xiaodong, Ma Qifeng, Wang Yandong, et al. Cyclic tests of replaceable shear links in steel coupling beams[J]. Journal of Building Structures, 2014, 35(6):1-11. (in Chinese) [12] 吕西林, 陈聪. 带有可更换构件的结构体系研究进展[J]. 地震工程与工程振动, 2014, 34(1):27-36. Lü Xilin, Chen Cong. Research progress in structural systems with replaceable members[J]. Earthquke Engineering and Engineering Dynamics, 2014, 34(1):27-36. (in Chinese) [13] Wolski M, Ricles J M, Sause R. Experimental study of a self-centering beam-column connection with bottom flange friction device[J]. Journal of Structural Engineering, 2009, 135(5):479-488. [14] 吴从晓, 周云, 徐昕, 等. 扇形铅黏弹性阻尼器滞回性能试验研究[J]. 建筑结构学报, 2014, 35(4):199-207. Wu Congxiao, Zhou Yun, Xu Xin, et al. Experimental investigation on hysteretic performance of sector lead viscoelastic damper[J]. Journal of Building Structures, 2014, 35(4):199-207. (in Chinese) [15] 张艳霞, 赵文占, 陈媛媛, 等. 长孔螺栓摩擦阻尼器试验研究[J]. 工程抗震与加固改造, 2015, 37(4):90-95. Zhang Yanxia, Zhao Wenzhan, Chen Yuanyuan, et al. Experimental research of slotted bolted friction device[J]. Earthquake Resistant Engineering and Retrofitting, 2015, 37(4):90-95. (in Chinese) [16] ECCS. Study of design of steel building in earthquake zones[R]. Doc. ECCS-TWG 1.3, No.47, 1986:3/1-3/71. -
